MARKETING INFORMATION

Premium Plus 4K for Business

The EV4340X features a spacious 42.5-inch screen with 4K resolution and USB Type-C connectivity for streamlined viewing and operation for the modern business professional.

Work Effectively on a Wide 42.5-inch 4K Screen

The monitor supports 4K (3840 x 2160 pixels) resolution, displaying four times the amount of information than standard Full HD (1920 x 1080 pixels) across a spacious 42.5-inch size screen. This provides more space for flexible arrangement of multiple applications without the obtrusive bezels characteristic of multi-monitor setups.

Get Connected. Get Started.

The monitor is equipped with a USB Type-C connection that allows users to display video, playback audio, transmit USB signals, supply power to connected devices, and even access a network signal. This convenient multi-purpose connectivity makes it faster and easier to connect your laptop when moving between workstations or working away from the office.

Power Delivery

The 94 watt power delivery via USB Type-C reliably charges laptops or small desktop PCs. This eliminates the need for a laptop's bulky power supply unit, freeing up space in your bag and on your desk.

Stable Network Connection

While many modern laptops are not equipped with a dedicated LAN port, the monitor has one directly built in for a wired connection. Connecting any laptop via USB Type-C allows access to the network through the monitor. This allows you to conduct conference calls or data transfers reliably and at high speed.

EIZO MAC Address Clone Utility software temporarily assigns the MAC address of a connected PC to the monitor, granting network access to authenticated devices, and preventing network access from unauthenticated devices.

Directly Connect Peripherals

While many modern laptops are designed to be thinner and more portable, they often have limited connectivity options for peripherals. Connecting a laptop to the monitor via USB Type-C provides access to a hub with two USB Type-A ports and one USB Type-C port for easily connecting an external keyboard, mouse, or headset.

A Better Meeting Experience

Many organizations are adopting open-space meeting areas for fostering engagement and inclusivity. The monitor includes many features and functions to facilitate an efficient and lively collaborative environment.

Make Open Meetings More Efficient

The Picture-by-Picture (PbyP) function allow the monitor to receive up to four video signals to be displayed side-by-side on one large screen. A switch on the front of the monitor allows you to select your preferred layout from a choice of 12. The monitor also has a Picture-in-Picture (PinP) function. This enables more streamlined screen sharing for efficient presentations and meetings.

Quality Speakers that are Barely There

The monitor's minimalistic front bezel houses two 4-watt speakers. Audio is clear whether the monitor is being used by an individual or by several people during meetings.

Remote Control for Easy Operation

The included remote control can be used to control volume, brightness, display input, PbyP, and other settings, as well as to turn the monitor on and off. This is useful when the user cannot reach the buttons on the front of the monitor, such as in wall-mounted installations.

DETAILS

• Number of Screens : 1
• Screen Size Class : 43"
• Viewable Screen Size : 42.5"
• Screen Mode : 4K UHD
• Panel Technology : In-plane Switching (IPS) Technology
• Response Time : 5 ms
• Response Time Details : 5ms GTG
• Pixel Pitch : 0.24500 mm x 0.24500 mm
• Horizontal Viewing Angle : 178°
• Vertical Viewing Angle : 178°
• Backlight Technology : LED
• Mount Type : Wall Mountable
• HDCP Supported : Yes
• Features : sRGB,Picture by Picture,Picture in Picture,Auto EcoView,On-screen Display (OSD),Ergonomic Design,Low Blue Light,Flicker-free,Remote Control,Clear Vision
• Horizontal Frequency : 31 kHz to 134 kHz - USB Type C,31 kHz to 134 kHz - DisplayPort,31 kHz to 135 kHz - HDMI
• Vertical Frequency : 29 Hz to 61 Hz - USB Type C,29 Hz to 61 Hz - DisplayPort,29 Hz to 61 Hz - HDMI
• Active Display Area (H x V) : 37.06" (941.20 mm) x 20.84" (529.40 mm)
• Maximum Resolution : 3840 x 2160
• Standard Refresh Rate : 60 Hz
• Color Supported : 16.77 Million Colors
• Native Contrast Ratio : 1,000:1
• Brightness : 350 cd/m²
• Pixel Per Inch (PPI) : 104
• Number of Speakers : 2
• Speakers : Yes
• Network (RJ-45) : Yes
• HDMI : Yes
• USB : Yes
• DisplayPort : Yes
• USB Type-C : Yes
• Number of HDMI Inputs : 2
• Total Number of HDMI Ports : 2
• Number of DisplayPorts : 1
• Number of USB Ports : 5
• Number of USB Type-B Ports : 1
• Total Number of USB Type-C Ports : 2
• USB Type-B : Yes
• Built-in Devices : USB Hub
• Operating Temperature Range : 41°F (5°C) to 95°F (35°C)
• Operating Humidity Range : 20% to 80% (Non-condensing)
• Operating Power Consumption : 31 W
• Maximum Power Consumption : 243 W
• VESA Mount Compatible : Yes
• Color Family : Black
• Color : Black
• Height : 22.48" (571 mm)
• Width : 38.06" (966.80 mm)
• Depth : 3.54" (89.90 mm)
• Height with Stand : 24.84" (631 mm)
• Width with Stand : 38.06" (966.80 mm)
• Depth with Stand : 8.87" (225.20 mm)
• Weight (Approximate) : 33.51 lb (15200 g)
• Weight with Stand (Approximate) : 35.05 lb (15900 g)
• Application/Usage : Conferencing
• Energy Star : Yes
• Environmentally Friendly : Yes
• Environmental Certification : Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
• Environmental Compliance : Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE),China Restriction of Hazardous Substances (China RoHS)
• Limited Warranty : 5 Year

• 5 ms response time makes it excellent for latest action films, sports or gaming
• Furnishes captivating visuals with 350 cd/m² brightness levels
• Experience breathtaking level of details when you open your eyes to the clarity of 4K UHD screen
• LED backlight enhances display performance that delivers an outstanding color range and contrast ratios
• Features HDMI input to get connected with the top of the line PCs, Blu-ray players, and cutting edge gaming consoles
• DisplayPort interface that transmits both audio and video signals through a single connection to deliver versatile performance
