Sharp AQOUS BOARD 4WB55FT5U Collaboration Display - LCD - Infrared (IrDA) - Touchscreen - 3840 x 2160 - LED - 270 cd/m² - 1,300:1 Contrast Ratio - 2160p - USB - HDMI - VGA
4WB55FT5U
Also known as SY7110234,IM674C1R
MARKETING INFORMATION
Sharp's 4WB series AQUOS BOARD® interactive displays add interoperability and collaboration to any environment.
Sharp 4WB55FT5U - 55" Class (54.6" diagonal) AQUOS BOARD® interactive display enables collaboration and communication in the workplace, classroom and virtually anywhere through precise 20-point multi-touch functionality and versatile connectivity. It is specified to continuously operate for up to 16-hours a day, 7-days a week, providing reliable performance in a classroom or office. A powerful RS-232C and LAN command set facilitates flexible wireless remote control from connected devices. Wireless screen casting** and an HTML5 browser allow for viewing various types of content onto the large format display.
This display of 4WB series includes integrated solutions such as:
HTML5 Browser App with an HTML5 browser, you can start signage quickly, leveraging your web-based content, while making your business or classroom more efficient.
Professional Command Control RS-232C and LAN command set enables flexible remote control from connected devices.
Multi OS Support. Plug & Play, your computer automatically recognizes the 4WB series displays when connected, without a complicated driver to install.
Public mode prevents unwanted adjustments by people in public locations such as classrooms and office spaces.
Screen Mirroring App, cast your personal device screen in real-time by mirroring your complete screen, including photos, videos, apps and websites onto the large format display.
DETAILS
- Display Screen Type : LCD
- Display Screen Technology : TFT LCD
- Backlight Technology : LED
- Screen Mode : 4K UHD
- Screen Resolution : 3840 x 2160
- Scan Format : 2160p
- Contrast Ratio : 1,300:1
- Brightness : 270 cd/m²
- Horizontal Viewing Angle : 178°
- Vertical Viewing Angle : 178°
- Touchscreen : Yes
- Multi-touch Screen : Yes
- Number of Touch Points : 20
- Touchscreen Technology : Infrared (IrDA)
- Speakers : Yes
- Number of Speakers : 2
- RMS Output Power : 16 W
- Ethernet : Yes
- Wireless LAN : Yes
- HDMI : Yes
- Total Number of USB Ports : 2
- USB : Yes
- Network (RJ-45) : Yes
- Audio Line In : Yes
- VGA : Yes
- Serial : Yes
- Software Included :
User-Friendly Sharp Pen Software
- Input Voltage : 120 V AC
- Power Consumption : 130 W
- VESA Mount Compatible : Yes
- VESA Mount Standard : 300 x 200
- Height : 29.50" (749.30 mm)
- Width : 49.80" (1264.92 mm)
- Depth : 3.30" (83.82 mm)
- Weight (Approximate) : 51.60 lb (23405.37 g)
- Limited Warranty : 3 Year
SPECIFICATIONS
| Manufacturer | Sharp Electronics |
| Manufacturer Part Number | 4WB55FT5U |
| Manufacturer Website Address | http://www.sharpusa.com |
| Brand Name | Sharp |
| Product Line | AQUOS BOARD |
| Product Series | 4W-B |
| Product Model | 4WB55FT5U |
| Product Name | AQOUS BOARD 4WB55FT5U Collaboration Display |
| Product Type | Collaboration Display |
| Display Screen Type | LCD |
| Display Screen Technology | TFT LCD |
| Backlight Technology | LED |
| Screen Mode | 4K UHD |
| Screen Resolution | 3840 x 2160 |
| Scan Format | 2160p |
| Color Supported | 1.07 Billion Colors |
| Contrast Ratio | 1,300:1 |
| Display Orientation | Landscape |
| Brightness | 270 cd/m² |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Number of Touch Points | 20 |
| Touchscreen Technology | Infrared (IrDA) |
| Speakers | Yes |
| Number of Speakers | 2 |
| RMS Output Power | 16 W |
| Ethernet | Yes |
| Ethernet Technology | Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11b/g/n/ac |
| HDMI | Yes |
| Number of HDMI Inputs | 3 |
| Total Number of USB Ports | 2 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Audio Line In | Yes |
| Number of VGA Ports | 1 |
| VGA | Yes |
| Serial | Yes |
| Software Included | User-Friendly Sharp Pen Software |
| Input Voltage | 120 V AC |
| Power Consumption | 130 W |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 300 x 200 |
| Height | 29.50" (749.30 mm) |
| Width | 49.80" (1264.92 mm) |
| Depth | 3.30" (83.82 mm) |
| Weight (Approximate) | 51.60 lb (23405.37 g) |
| Package Contents |
|
| Limited Warranty | 3 Year |
