MARKETING INFORMATION

Extend Connectivity and Improve Network Availability

FortiExtender offers scalable, cost-effective, and resilient 5G and LTE solutions. Driven by Fortinet's unique approach of Security-driven networking FortiExtender allows organizations business continuity, improved network availability while securing connectivity with wired broadband and cellular networks.

From secure point of sale (POS) systems to vehicle fleet communication, FortiExtender provides reliable broadband access to the internet and extends the value of the Fortinet Security Fabric to support fluid business operations dependent on remote device connectivity.

Security Fabric Integration

Integration with Fortinet SD-WAN and FortiGate appliances secures internet edge breakouts with a complete set of Web, Content, and Device security controls far beyond other industry solutions.

Optimal Signal Strength

A single PoE cable provides optimal 5G/LTE signal vs complex, lossy antenna cables or limited strength USB modems. Dual SIM and Dual Modem options offer up to 5X network reliability.

Simplified Management

Manage your FortiExtender from the FortiManager, FortiGate, or FortiExtender Cloud dashboard, making network changes, security controls, and policy automation simple.

FEATURES | Superior Management, Security, and Control

FortiExtenders are a true plug-and-play device. Once connected to the FortiGate, they appear as a regular network interface in FortiOS management. IT administrators can manage the connection as well as implement complete UTM security and control, just like any other FortiGate interface. In addition, FortiOS will display data quota usage on the wireless WAN interface, providing complete visibility of the connection to ensure costly carrier data limits are not exceeded. The superior management, security, and control of the FortiExtender ultimately reduces IT costs while extending, ensuring, and securing the network.

Flexible Deployment for Optimal Signal Strength

FortiExtender devices are designed to receive the best possible 5G/LTE signal. The device utilizes Power over Ethernet (PoE) so you can run a high-quality ethernet cable to a location with optimal signal strength, up to 100m away from the FortiGate or Network Switch.

DETAILS

• Network Band : Quad Band
• Broadband Transmission Technology : Ethernet,Cellular
• Cellular Generation : 4G
• Cellular Data Connectivity Technology : HSPA+,LTE,UMTS
• Total Number of Antennas : 3
• Number of External Antennas : 3
• Number of Network (RJ-45) Ports : 4
• PoE (RJ-45) Port : Yes
• Number of Broadband (RJ-45) Ports : 1
• Ethernet Technology : Gigabit Ethernet
• Multi-SIM Supported : Yes
• Number of SIM Card Supported : 2
• SIM Size Supported : Micro
• Form Factor : Desktop,Wall Mountable
• Height : 1.45" (36.83 mm)
• Width : 5.90" (149.86 mm)
• Depth : 5.90" (149.86 mm)
• Weight (Approximate) : 12.96 oz (367.41 g)
