MARKETING INFORMATION

Cisco^® 1000 Series Integrated Services Routers (ISRs) with Cisco IOS^® XE Software combine Internet access, comprehensive security, and wireless services (LTE Advanced 3.0 wireless WAN and 802.11ac wireless LAN) in a single, high-performance device. The routers are easy to deploy and manage, with separate data and control plane capabilities.

The Cisco 1000 Series ISRs are well suited for deployment as Customer Premises Equipment (CPE) in enterprise branch offices, in service provider managed environments as well as smaller form factor and M2M use cases.

DETAILS

• Broadband Transmission Technology : Ethernet,Cellular
• ISM Band : No
• UNII Band : No
• Cellular Generation : 4G
• Cellular Network Supported : LTE 700,LTE 800,LTE 850,LTE 900,LTE 1700,LTE 1800,LTE 1900,LTE 2100,LTE 2300,LTE 2500,LTE 2600
• Cellular Data Connectivity Technology : LTE Advanced,UMTS,HSPA+,DC-HSPA+
• Total Number of Antennas : 2
• Number of External Antennas : 2
• Number of Network (RJ-45) Ports : 8
• USB : Yes
• PoE (RJ-45) Port : Yes
• Number of Broadband (RJ-45) Ports : 2
• Ethernet Technology : Gigabit Ethernet
• Multi-SIM Supported : Yes
• Number of SIM Card Supported : 2
• SIM Size Supported : Micro
• Form Factor : Desktop,Rack-mountable
• Height : 1.75" (44.45 mm)
• Width : 12.70" (322.58 mm)
• Depth : 9.60" (243.84 mm)
• Weight (Approximate) : 4.50 lb (2041.17 g)
• Package Contents :
  • 1100 Integrated Services Router
  • 2 x Multiband Swivel-mount Dipole Antennas
  • Rubber Feet
• Environmentally Friendly : Yes
• Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)
• Country of Origin : China
• Limited Warranty : 1 Year

• Gigabit Ethernet port for ultra-fast wired network speeds
• Access USB-compatible peripherals accross the wireless network via built-in USB port
