MARKETING INFORMATION

Why do you need Wi-Fi 6 (11ax)? Because your smart home isn't reaching the limits of its potential. The most common Wi-Fi standards in use today simply aren't built to support multiple personal devices and smart home gadgets running simultaneously 24/7. The DIR-X4860 AX4800 Wi-Fi Router brings next-generation Wi-Fi technology into your home, giving you the quantum leap in capacity and bandwidth to support more devices at once. By combining high-speed 802.11ax Wi-Fi with dual-band technology and Gigabit Ethernet ports, the DIR-X4860 provides a seamless networking experience with a high degree of convenience and flexibility.

Mind-Blowing Speed and Range

The DIR-X4860 AX4800 Wi-Fi Router brings a host of new technologies to create the best wireless networking experience to date. Unlike the existing 11ac wireless standard that operates only in the 5 GHz range, Wi-Fi 6 fully utilizes both 2.4 GHz and 5 GHz bands. It also comes with 1024 QAM to boost throughput to devices by up to 25%, and 160 MHz contiguous channel width for even more bandwidth. All this adds up to whopping combined speeds of up to 4,800 Mbps (600 Mbps + 4,200 Mbps). Built-in Power Amplifiers and beamforming extend the reach of your Wi-Fi and direct the signals where they need to go. Wi-Fi 6 lets you unleash all that lightning-fast Wi-Fi goodness over larger areas than ever - from bedroom and bathroom all the way to basement and backyard.

Made for Smart Home

The DIR-X4860 upgrades your network to the latest Wi-Fi 6 wireless technology which supports 6 simultaneous streams so it easily handles all the connected devices you can throw at it all at the same time. Enjoy simultaneous throughput to multiple devices for seamless high definition streaming media, VR gaming, and cloud storage. In addition, the 10/100/1000 Mbps Gigabit Ethernet WAN port gives you fast paced Internet access, future proofing your Internet. The built-in Quality of Service (QoS) engine allows you to prioritize traffic to your preferred client, ensuring that your favorite devices are receiving optimal bandwidth.

Exceptional Capacity

If you thought MU-MIMO in your Wi-Fi was cool, wait till you meet Orthogonal Frequency Division Multiple Access (OFDMA). It's a signature technology in Wi-Fi 6 that splits a channel into four sub-channels. The result? Signals from multiple devices get transmitted together in one shot and never have to queue up again. Get an incredible 4x boost in your bandwidth capacity - perfect for smart homes filled with bandwidth-hungry IoT devices threatening to devour your Wi-Fi capacity.

DETAILS

• Virtual Assistant Supported : Alexa/Google Assistant
• Wi-Fi Generation : Wi-Fi 6
• Network Band : Dual Band
• Broadband Transmission Technology : Ethernet
• Wireless LAN Standard : IEEE 802.11ax
• ISM Band : Yes
• UNII Band : Yes
• ISM Maximum Frequency : 2.40 GHz
• UNII Maximum Frequency : 5 GHz
• Total Number of Antennas : 6
• Number of External Antennas : 6
• Total Wireless Transmission Speed : 600 MB/s
• Number of Network (RJ-45) Ports : 4
• USB : Yes
• Number of Broadband (RJ-45) Ports : 1
• Ethernet Technology : Gigabit Ethernet
• Form Factor : Desktop
• Height : 8.32" (211.32 mm)
• Width : 13.34" (338.80 mm)
• Depth : 9.50" (241.35 mm)
• Weight (Approximate) : 1.61 lb (732 g)

• Gigabit Ethernet port for ultra-fast wired network speeds
• Uses ISM Band to connect your computers, wireless printers, game consoles, and other Wi-Fi devices for a smooth network experience
• Access USB-compatible peripherals accross the wireless network via built-in USB port
• Desktop installation - Ideal for deployments outside the wiring closet
