Middle Atlantic Select 2RU UPS Battery Backup Power - 2200VA UPS Backup - 8 Outlet - Basic Surge Protection - 2U Rack-mountable - AVR - 4 Minute Stand-by - 120 V AC Input - 120 V AC Output - 8 x NEMA 5-20R Receptacle(s)

UPS-S2200R
Also known as SY6478342

New! Log in or create an account to see price and availability


MARKETING INFORMATION

Select Series UPS Battery Backup Systems are a competitively priced option for ensuring uptime of equipment in the event of a power outage or power anomaly. Select UPS backups are designed for both AV and Security applications. Plug it in, feel confident, and simply focus on creating an amazing AV experience. The control you need to remotely monitor the uptime of your equipment. If remote monitoring and control of the UPS is necessary for your AV system, you can achieve that with an optional IP card. Quality protection without the price tag. Select UPS backups use a simulated sine wave, keeping the cost down while keeping your equipment protected and powered. Make the switch (almost instantly.) In just 8ms of a power outage or anomaly, the UPS will transfer equipment to battery power. Prevent the silent death of your equipment. Over and under voltage slowly degrade your equipment and shorten its lifespan. With automatic voltage regulation (AVR), the UPS will switch to battery and power your equipment till the voltage returns to a normal level. Choose which equipment to prioritize. With separate critical and non-critical outlet banks, should an extended power outage occur, the UPS will cease powering the non-critical equipment via load shedding. Protect your equipment. Each UPS backup comes with basic surge protection and EMI filtering. Stay in the know. An LED status indicator on the front of the UPS assures you your equipment is still being powered, and alerts you of low battery level, or of battery overload. Replace the battery pack with ease. The hot-swappable battery pack can be easily replaced via the front panel for easy service without disrupting the system.

DETAILS

  • AVR : Yes
  • Plug/Connector Type : NEMA 5-20P
  • Receptacle Type : NEMA 5-20R
  • Receptacle Detail : 8 x NEMA 5-20R
  • Number of Critical Load Outlets : 4
  • Overload Protection : Yes
  • Transfer Time : 8 ms
  • EMI/RFI Noise Filter : Yes
  • Load Capacity (VA) : 2.20 kVA
  • Load Capacity (Watt) : 1.32 kW
  • Input Voltage : 120 V AC
  • Input Voltage Range : 90 V AC - 140 V AC
  • Output Voltage : 120 V AC
  • Waveform Type : Simulated Sine Wave
  • Surge Energy Rating : 1840 J
  • EPO Port : Yes
  • USB (HID Compliant) Port : Yes
  • Number of Batteries : 4
  • Battery Size : 12V
  • Battery Capacity : 9000 mAh
  • Backup/Run Time (Full Load) : 4 Minute
  • Backup/Run Time (Half Load) : 13 Minute
  • Replaceable Battery : Yes
  • Operating Humidity : 0% - 95%
  • Maximum Operating Temperature : 104°F (40°C)
  • Height : 3.46" (87.88 mm)
  • Width : 19" (482.60 mm)
  • Depth : 16.50" (419.10 mm)
  • Rack Height : 2U
  • Form Factor : Rack-mountable
  • Weight (Approximate) : 52.70 lb (23904.32 g)
  • Package Contents :
    • Select UPS-S2000R 2200VA Rack-mountable UPS
    • 10' Power Cord
  • Environmentally Friendly : Yes
  • Environmental Certification : GREENGUARD
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Limited Warranty : 3 Year
  • Compact in size and offers highly efficient solution
  • Keep your sensitive devices powered with a backup of up to 4 minute at full load
  • Prevent critical data loss by staying powered during a blackout with up to 1.32 kW load capacity
  • 2.20 kVA load capacity - work without any interruption during power outages

SPECIFICATIONS

Manufacturer Legrand Group
Manufacturer Part Number UPS-S2200R
Manufacturer Website Address http://www.legrand.com
Brand Name Middle Atlantic
Product Line Select
Product Model UPS- S2000R
Product Name Middle Atlantic Select Series 2RU UPS Battery Backup Power - 2200VA UPS Backup
Product Type Standby UPS
AVR Yes
Plug/Connector Type NEMA 5-20P
Receptacle Type NEMA 5-20R
Receptacle Detail 8 x NEMA 5-20R
Number of Critical Load Outlets 4
Overload Protection Yes
Transfer Time 8 ms
EMI/RFI Noise Filter Yes
Load Capacity (VA) 2.20 kVA
Load Capacity (Watt) 1.32 kW
Input Voltage 120 V AC
Input Voltage Range 90 V AC - 140 V AC
Output Voltage 120 V AC
Waveform Type Simulated Sine Wave
Surge Energy Rating 1840 J
EPO Port Yes
USB (HID Compliant) Port Yes
Number of Batteries 4
Battery Size 12V
Battery Capacity 9000 mAh
Backup/Run Time (Full Load) 4 Minute
Backup/Run Time (Half Load) 13 Minute
Replaceable Battery Yes
Maximum Operating Temperature 104°F (40°C)
Operating Humidity 0% - 95%
Height 3.46" (87.88 mm)
Width 19" (482.60 mm)
Depth 16.50" (419.10 mm)
Rack Height 2U
Form Factor Rack-mountable
Weight (Approximate) 52.70 lb (23904.32 g)
Package Contents
  • Select UPS-S2000R 2200VA Rack-mountable UPS
  • 10' Power Cord
Environmentally Friendly Yes
Environmental Certification GREENGUARD
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Limited Warranty 3 Year
