MARKETING INFORMATION

Incredible Immersion with Ultra-Narrow Bezel

The VL5F series video wall provides an immersive experience thanks to its ultra-narrow 3.5 mm bezel-to-bezel, while its outstanding IPS panel delivers a clear image from virtually any angle. The design of this video wall display is attractive and highly functional and can be used to deliver advertising and information in a variety of business environments.

Achieving Incredible Immersion

3.5mm Ultra-narrow Bezel

The 3.5mm ultra-narrow bezel of the 55VL5F-A video wall creates a visually stunning digital wall that delivers dynamic content and immerses the viewer. The 55" screens can be combined to create a virtually seamless large screen.

Achieving Incredible Immersion

Image Gap Reduction

The VL5F series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a virtually seamless viewing experience.

Vivid and Dynamic Picture Quality

Higher Viewing Angle

Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5F series is high enough to display vivid colors throughout the screen with virtually no distortion.

Vivid and Dynamic Picture Quality

Wider Viewing Angle

It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5F series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.

User Convenience

Easy Color Adjustment

Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

User Convenience

Simple White Balance Adjustment

In conventional video walls, white balance was adjustable only in "full-white" mode, but the VL5F series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.

User Convenience

User-Friendly Menu Structure

The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.

User Convenience

Intuitive GUI

The GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a larger font for better visibility, which may be necessary when users want to control displays from relatively far distances.

DETAILS

• Video Wall Compatible : Yes
• Bezel Width (Top) : 88.58 mil (2.25 mm)
• Bezel Width (Bottom) : 49.21 mil (1.25 mm)
• Bezel Width (Left) : 88.58 mil (2.25 mm)
• Bezel Width (Right) : 49.21 mil (1.25 mm)
• Viewable Screen Size : 55" (1397 mm)
• Display Screen Type : LCD
• Display Resolution : 1920 x 1080
• Backlight Technology : LED
• Maximum LED Life : 6.8 Year
• Scan Format : 1080p
• Dynamic Contrast Ratio : 500,000:1
• Brightness : 500 cd/m²
• Ethernet : Yes
• USB : Yes
• DVI : Yes
• HDMI : Yes
• Serial : Yes
• Number of HDMI Inputs : 2
• Input Voltage : 120 V AC,230 V AC
• Color Family : Black
• Product Color : Black
• Bezel Color : Black
• VESA Mount Compatible : Yes
• VESA Mount Standard : 600 x 400
• Height : 26.94" (684.20 mm)
• Width : 47.77" (1213.40 mm)
• Depth : 3.67" (93.10 mm)
• Weight (Approximate) : 44.75 lb (20300 g)
• Minimum Operating Temperature : 32°F (0°C)
• Maximum Operating Temperature : 104°F (40°C)
• Minimum Operating Humidity : 10%
• Maximum Operating Humidity : 80%
• Energy Star : Yes
• Environmentally Friendly : Yes
• Energy Efficiency Certification : ENERGY STAR 7.0
• Country of Origin : Mexico

• Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
• Experience luminescent visual images with LCD display
• Offers exceptionally smooth and crisp viewing experience due to its 1920 x 1080 full HD resolution
• Features 1920 x 1080 resolution and 1080p scan format for producing sharp and bright images
• LED backlighting offers a fine uniformity to display effective pictures at a low cost
