StarTech.com 7m (22ft) LC/UPC to LC/UPC OM3 Multimode Fiber Optic Cable, Full Duplex 50/125 Zipcord, 100G, LSZH Fiber Jumper Cord - 7m (22ft) OM3 Multimode LC/LC-UPC Fiber Cable; 1/10/40/100 Gbps Full Duplex; 50/125um Core w/ Aramid Sheath; Bandwidth: 2000MHz·km at 850nm w/ VCSEL source; Outer Diame
A50FBLCLC7
Also known as SY6388405
MARKETING INFORMATION
This OM3 LC to LC Multimode Duplex Fiber Optic Patch cable features 50/125 micron fiber and supports high-bandwidth data transmission over a 10 Gigabit Ethernet connection.
Built for Performance
With laser-optimized multimode fiber (LOMMF), the patch cable is ideal for connecting 850 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. The high-speed connectivity on the aqua fiber-optic cable provides a high-bandwidth solution for your data centers or high-density applications.
Reliable Connection
Each OM3 fiber cable is individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.
High-Quality Construction
Housed in a LSZH (Low-Smoke, Zero-Halogen) flame retardant jacket, this fiber-optic cable ensures minimal smoke, toxicity and corrosion when exposed to high sources of heat, or in the event of a fire. It's the best choice for a wide range of environments, including industrial settings, central offices and schools, as well as residential settings where building codes are a consideration.
A50FBLCLC7 is backed by a StarTech.com lifetime warranty and free lifetime technical support.
DETAILS
- Cable Type : Fiber Optic
- Cable Characteristic : Patch Cable
- Fiber Optic Mode : Multi-mode
- Fiber Optic Cable Core/Cladding Specification : 50/125 µm
- Cable Length : 23 ft (7 m)
- Connector Type on First End : LC Network - Male
- Connector Gender on First End : Male
- Connector on First End Details : 2 x LC Network - Male
- Connector Type on Second End : LC Network - Male
- Connector Gender on Second End : Male
- Connector on Second End Details : 2 x LC Network - Male
- Device Supported : Network Device
- Data Transfer Rate : 10 Gbit/s
- Features : Halogen Free,Flame Retardant,Corrosion Resistant
- Color Family : Green
- Product Color : Aqua
- Country of Origin : China
- Limited Warranty : Lifetime
- OM3 FIBER CABLE: OM3 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
- QUALITY CONSTRUCTION: 50/125µm fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/LC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
- RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes in case of fire; TIA/EIA compliant fiber core; Attenuation value under 2.3dB/km meets or exceeds industry standards
- WIDE COMPATIBILITY: OM3 LC/LC multimode cable supports 1/10/40/100 Gbps networks; Backward compatible with OM3; For high-density network applications such as SANs, data servers, fiber switches, SFP+, QSFP+, and QSFP28 transceivers
- SPECS: 7m (23ft); Color: Aqua (OM3); LC/LC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ≥2000MHz·km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life
SPECIFICATIONS
Manufacturer | StarTech.com |
Manufacturer Part Number | A50FBLCLC7 |
Manufacturer Website Address | http://www.startech.com |
Brand Name | StarTech.com |
Product Name | Fiber Optic Duplex Patch Network Cable |
Packaged Quantity | 1 Each |
Product Type | Network Cable |
Cable Type | Fiber Optic |
Cable Characteristic | Patch Cable |
Fiber Optic Mode | Multi-mode |
Cable Length | 23 ft (7 m) |
Connector Type on First End | LC Network - Male |
Connector Gender on First End | Male |
Connector on First End Details | 2 x LC Network - Male |
Connector Type on Second End | LC Network - Male |
Connector Gender on Second End | Male |
Connector on Second End Details | 2 x LC Network - Male |
Device Supported | Network Device |
Data Transfer Rate | 10 Gbit/s |
Features | Corrosion Resistant |
Features | Halogen Free |
Features | Flame Retardant |
Color Family | Green |
Product Color | Aqua |
Shipping Height | 0.59" (14.99 mm) |
Shipping Width | 8.66" (219.96 mm) |
Shipping Weight (Approximate) | 3.36 oz (95.25 g) |
Country of Origin | China |
Limited Warranty | Lifetime |
