MARKETING INFORMATION

Discover a new level of interaction using the power of Android

Get even closer to your audience than ever before. Fast, precise and extremely durable,
its high performance is matched by excellent reliability and functionality.

Innovative solutions for any signage application

• Android: Run your own app or choose your favorite app to run
• Enhance your connectivity with an integrated mPCIe slot.
• Integrated WiFi
• Save and play content with internal memory

Maximizing the impact of your message

• CMND: Take control of your displays

Care about you, your business and your audience

• Ensure your content is running with automatic screenshots
• Keep your content up and running with FailOver

Supreme audience interaction

• True multi touch with 6 simultaneous touch points
• Experience amazing interactivity with true Multi-Touch
• Anti-glare glass with low optical parallax

Highlights | Powered by Android

WIth Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day and with the auto orientation feature, showing content in portrait or landscape is as simple as turning the display.

PCI Slot

With an integrated PCI slot, you can connect a WiFI/bluetooth or 4G LTE module, allowing for even greater communication with the display. Machine to machine communication is also enhanced, with numerous configurations available for customers to use, such as the ability to expand product features or signalhandling capability.

Internal Memory

Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.

Proof of Play

Content is king, and with the automatic screenshot feauture, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.

FailOver

Keeping your content up and running is critical for demanding commercial applications. While it is unlikely you will face a content disaster, FailOver provides content protection with a revolutionary technology that plays back-up content on screen in the event of a media player failure. FailOver automatically kicks in when the primary input fails. Simply select a primary input connection and a FailOver connection and your ready for instant protection.

CMND

A robust display management platform, CMND puts the power back into your hands. Update and manage content with CMND &Create or control your settings with CMND & Control. It's all possible with CMND.

6 simultaneous touch points

Enjoy a more interactive experience with up to 6 touch points at the same time. Ideal for when you have more than one user to interact with your application simultaneously, the 6 touch points offer an extremely cost-effective solution.

DETAILS

• Bezel Width (Top) : 0.37" (9.50 mm)
• Bezel Width (Bottom) : 0.61" (15.60 mm)
• Bezel Width (Left) : 0.37" (9.50 mm)
• Bezel Width (Right) : 0.37" (9.50 mm)
• Processor Type : Cortex A9
• Processor Speed : 1.80 GHz
• Processor Core : Quad-core (4 Core)
• Standard Memory : 3 GB
• Memory Technology : DDR3 SDRAM
• Number of Screens : 1
• Viewable Screen Size : 48.50" (1231.90 mm)
• Display Screen Type : LCD
• Multi-touch Screen : Yes
• Touchscreen : Yes
• Display Resolution : 1920 x 1080
• Scan Format : 1080p
• Dynamic Contrast Ratio : 500,000:1
• Brightness : 450 cd/m²
• Ethernet : Yes
• Wireless LAN : Yes
• USB : Yes
• DVI : Yes
• HDMI : Yes
• DisplayPort : Yes
• Serial : Yes
• Number of HDMI Inputs : 2
• Operating System : Android
• Input Voltage : 120 V AC,230 V AC
• Color Family : Black
• Product Color : Black
• VESA Mount Standard : 400 x 400
• Height : 24.90" (632.46 mm)
• Width : 43.20" (1097.28 mm)
• Depth : 1.80" (45.72 mm)
• Weight (Approximate) : 32.41 lb (14700 g)
• Package Contents :
  • Signage Solutions Multi-Touch Display
  • Remote Control
  • Batteries for Remote Control
  • Quick Start Guide
  • RS232 Cable
  • AC Power Cord
• Energy Star : Yes
• Environmentally Friendly : Yes
• Environmental Compliance : Restriction of Hazardous Substances (RoHS),Japanese Restriction of Hazardous Substances
• Energy Efficiency Certification : ENERGY STAR 7.0
• Country of Origin : China
• Limited Warranty : 3 Year

• Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
• Cortex A9 1.80 GHz processor executes heavy and power-hungry applications seamlessly with efficient-power
• Experience luminescent visual images with LCD display
• Features full 1920 x 1080 HD resolution enabling sharp and clear images
• Engages your customers and makes their viewing experience breathtaking with its 1080p content
