CyberPower OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS - Rack-mountable - 10 Hour Recharge - 6.60 Minute Stand-by - 120 V AC Input - 120 V AC Output - Serial Port - USB - 8 x NEMA 5-15R Receptacle(s)

OR1000PFCRT2U
Also known as SY5705391

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The CyberPower OR1000PFCRT2U PFC Sinewave UPS System with sine wave output and multifunction LCD safeguards networking hardware, networked-based devices, small office servers, workstations and telecom equipment that use conventional and Active Power Factor Correction (PFC) power supplies.

The OR1000PFCRT2U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently.

This UPS is patented GreenPower UPS™ Bypass circuitry to save on energy costs by reducing energy consumption and heat buildup.

A Three-Year Warranty ensures that this UPS has passed our highest quality standards in design, assembly, material or workmanship and further protection is offered by a $300,000 Connected Equipment Guarantee.
  • 1000 VA load capacity provides sufficient backup during power failures
  • Prevent critical data loss by staying powered during a blackout with up to 700 W load capacity
  • Up to 6.60 minute runtime on full load to preserve critical data from power shortage interruptions

DETAILS

  • Plug/Connector Type : NEMA 5-15P
  • Receptacle Type : NEMA 5-15R
  • Receptacle Detail : 8 x NEMA 5-15R
  • Dataline Protection : RJ-11,RJ-45
  • Overload Protection : Yes
  • EMI/RFI Noise Filter : Yes
  • Load Capacity (VA) : 1 kVA
  • Load Capacity (Watt) : 700 W
  • Input Voltage : 120 V AC
  • Output Voltage : 120 V AC
  • Waveform Type : Sine Wave
  • Surge Energy Rating : 1470 J
  • Alarm : On Battery,Low Battery,Overload
  • Status Indicators :
    • Power On
    • Wiring Fault
  • Serial Port : Yes
  • USB : Yes
  • Network (RJ-45) : Yes
  • Number of Batteries : 2
  • Battery Chemistry : Lead Acid
  • Backup/Run Time (Full Load) : 6.60 Minute
  • Backup/Run Time (Half Load) : 17.90 Minute
  • Typical Battery Recharge Time : 10 Hour
  • Height : 3.50" (88.90 mm)
  • Width : 17.01" (432.05 mm)
  • Depth : 15.32" (389.13 mm)
  • Form Factor : Rack-mountable
  • Weight (Approximate) : 37.40 lb (16964.35 g)
  • Package Contents :
    • OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS
    • USB A-B Cable
    • User's Manual
    • Software Download Card
    • Registration Info Card
  • Software Included : PowerPanel Business Edition
  • Energy Star : No
  • Country of Origin : China
  • Environmentally Friendly : Yes
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Limited Warranty : 3 Year
  • Works adequately in situations where the supply is prone to sags and surges
  • Keep your sensitive devices powered with a backup of up to 6.60 minute at full load
  • Prevent critical data loss by staying powered during a blackout with up to 700 W load capacity
  • 1 kVA load capacity - work without any interruption during power outages

SPECIFICATIONS

Manufacturer CyberPower Systems, Inc
Manufacturer Part Number OR1000PFCRT2U
Manufacturer Website Address https://www.cyberpowersystems.com/
Brand Name CyberPower
Product Series PFC Sinewave UPS
Product Model OR1000PFCRT2U
Product Name OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS
Product Type Line-interactive UPS
Plug/Connector Type NEMA 5-15P
Receptacle Type NEMA 5-15R
Receptacle Detail 8 x NEMA 5-15R
Dataline Protection RJ-45
Dataline Protection RJ-11
Overload Protection Yes
EMI/RFI Noise Filter Yes
Load Capacity (VA) 1 kVA
Load Capacity (Watt) 700 W
Input Voltage 120 V AC
Output Voltage 120 V AC
Waveform Type Sine Wave
Surge Energy Rating 1470 J
Alarm On Battery
Alarm Low Battery
Alarm Overload
Status Indicators
  • Power On
  • Wiring Fault
Serial Port Yes
Modem (RJ-11) Yes
Network (RJ-45) Yes
USB Yes
Number of Batteries 2
Battery Chemistry Lead Acid
Backup/Run Time (Full Load) 6.60 Minute
Backup/Run Time (Half Load) 17.90 Minute
Typical Battery Recharge Time 10 Hour
Height 3.50" (88.90 mm)
Width 17.01" (432.05 mm)
Depth 15.32" (389.13 mm)
Form Factor Rack-mountable
Weight (Approximate) 37.40 lb (16964.35 g)
Package Contents
  • OR1000PFCRT2U PFC Sinewave 1000VA Rack-mountable UPS
  • USB A-B Cable
  • User's Manual
  • Software Download Card
  • Registration Info Card
Additional Information
  • Input Voltage Range: 88Vac - 139Vac
  • Input Frequency: 60Hz ±3Hz
  • Automatic Voltage Regulation: Yes, +14%
  • Output Waveform: Sine wave
  • Output Voltage: 120Vac ±5%
  • Output Frequency: 60Hz ±1%
  • Overload Protection: Internal Circuitry Limiting
  • LCD: Internal Circuitry Limiting
  • Alarm: On Battery, Low Battery, Overload
  • Battery Size:12V / 9Ah
  • Replacement Battery Quantity: 1
  • Replacement Battery Model: RB1290X4H
  • Connected Equipment Guarantee: Lifetime
  • CEG Amount: $300,000
Certifications & Standards
  • cUL
  • UL 1778 5th Ed
  • FCC Class A
Software Included PowerPanel Business Edition
Energy Star No
Country of Origin China
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Limited Warranty 3 Year
