Tripp Lite series Cat5e 350 MHz Bulk Solid-Core PVC Cable, Blue, 1000 ft., TAA - 1000 ft (304.80 m) Category 5e Network Cable for Network Device, Router, Patch Panel, Switch - First End: Bare Wire - Second End: Bare Wire - 1 Gbit/s - Patch Cable - 24 AWG - Blue

N022-01K-BL
Also known as SY5685799

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The N022-01K-BL Cat5e 350 MHz Bulk Solid-Core PVC Cable is premium cabling designed for Cat5/5e premise applications, such as connecting an Ethernet wall jack to a router, patch panel or switch. Designed for fast transmission and excellent signal quality, this blue cable ensures peak performance through your LAN (local area network).

Manufactured from 24 AWG copper wire, the four-pair solid UTP N022-01K-BL delivers speeds up to 350 MHz/1 Gbps. Protected by a CMR-rated PVC jacket, this cable is ideal for all non-plenum horizontal wiring applications, including 10/100/1000 Base-T Ethernet, 100 Mbps TPDDI, 155 Mbps ATM, ISDN, voice and Token Ring Type 3 applications.

The N022-01K-BL meets most current industry standards, including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801 and ETL (category 5e, draft 11).

DETAILS

  • Cable Type : Category 5e
  • Cable Characteristic : Patch Cable
  • Cable Length : 1000 ft (304.80 m)
  • Connector Type on First End : Bare Wire
  • Connector on First End Details : Bare Wire
  • Connector Type on Second End : Bare Wire
  • Connector on Second End Details : Bare Wire
  • Device Supported : Network Device,Router,Patch Panel,Switch
  • American Wire Gauge : 24 AWG
  • Data Transfer Rate : 1 Gbit/s
  • Color Family : Blue
  • Product Color : Blue
  • Environmentally Friendly : Yes
  • Country of Origin : South Korea
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • TAA Compliant : Yes
  • Limited Warranty : Lifetime
  • Ideal for all non-plenum horizontal wiring applications
  • Rated for 350 MHz/1 Gbps communications
  • High-quality 24 AWG 4-pair solid copper wire
  • CMR-rated PVC jacket
  • Meets IEEE 802.3ab and ANSI/EIA/TIA 568 standards

SPECIFICATIONS

Manufacturer Eaton Corporation
Manufacturer Part Number N022-01K-BL
Manufacturer Website Address http://www.eaton.com/EatonCom/Markets/NorthAmerica
Brand Name Tripp Lite series
Product Model N022-01K-BL
Product Name Cat5e 350 MHz Bulk Solid-Core PVC Cable, Blue, 1000 ft., TAA
Package Type Bulk
Product Type Network Cable
Cable Type Category 5e
Cable Characteristic Patch Cable
Cable Length 1000 ft (304.80 m)
Connector Type on First End Bare Wire
Connector on First End Details Bare Wire
Connector Type on Second End Bare Wire
Connector on Second End Details Bare Wire
Device Supported Network Device
Device Supported Switch
Device Supported Patch Panel
Device Supported Router
American Wire Gauge 24 AWG
Data Transfer Rate 1 Gbit/s
Color Family Blue
Product Color Blue
Shipping Height 10.63" (270 mm)
Shipping Width 13.78" (350.01 mm)
Shipping Weight (Approximate) 21.90 lb (9933.67 g)
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Country of Origin South Korea
TAA Compliant Yes
Limited Warranty Lifetime
