Tripp Lite series U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter - USB 3.1 - 1 Port(s) - 1 - Twisted Pair - 10/100/1000Base-T - Desktop

U436-06N-G-C
Also known as SY5685792

Tripp Lite series U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter - USB 3.1 - 1 Port(s) - 1 - Twisted Pair - 10/100/1000Base-T - Desktop Ethernet NIC Network Adapter with USB-C Charging

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter allows USB Type-C computers, laptops, tablets and other compatible devices without an NIC (Network Interface Controller) to connect to a network or the Internet using an RJ45 cable. It's a more convenient and less expensive way to connect to a network than opening your device and installing an internal Ethernet card.

No software or drivers are needed. Connect the adapter's USB-C male plug to the USB-C port on your device. Then, connect the adapter's RJ45 port to a network using a UTP cable, such as Tripp Lite's N201-Series Cat6 cables. The U436-06N-G-C allows you to transfer data quickly and stream audio and video at true 10/100/1000 Mbps Ethernet speeds.

The USB-C charging port supports power input up to 20V 3A (60W). It powers the device that the U436-06N-G-C is plugged into by connecting the charging port to a USB-C wall charger.

Compliant with IEEE 802.3, 802.3u, 802.3ab and 802.3az standards. Supports 10/100/1000 auto-sensing, twisted-pair crossover detection, auto-correction and Wake-on-LAN power management. Compatible with Windows, Mac and Chromium operating systems. Backward compatible with previous USB versions.

DETAILS

  • Host Interface : USB 3.1
  • Total Number of Ports : 1
  • Number of Network (RJ-45) Ports : 1
  • Media Type Supported : Twisted Pair
  • Network Technology : 10/100/1000Base-T
  • Form Factor : Desktop
  • Package Contents :
    • U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter
    • Owner's Manual
  • Device Supported : Notebook,Computer,Tablet
  • Environmentally Friendly : Yes
  • Country of Origin : Vietnam
  • Limited Warranty : 3 Year
  • Enjoy the super fast Gigabit Ethernet connection by inserting this Gigabit Ethernet card into your computer
  • No need to intrude into the system's hard drive components for inserting an Ethernet card, just convert a USB port into an Ethernet port with this network adapter
  • Add your computer to your home or office network with this single port gigabit ethernet card conveniently
  • Supports cost-efficient twisted pair cables for speedy data transfer up to 100 meters
  • With the 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over the twisted pair cable

SPECIFICATIONS

Manufacturer Eaton Corporation
Manufacturer Part Number U43606NGC
Manufacturer Website Address http://www.eaton.com/EatonCom/Markets/NorthAmerica
Brand Name Tripp Lite series
Product Model U436-06N-G-C
Product Name U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter
Product Type Gigabit Ethernet Card
Host Interface USB 3.1
Total Number of Ports 1
Number of Network (RJ-45) Ports 1
Media Type Supported Twisted Pair
Network Technology 10/100/1000Base-T
Form Factor Desktop
Package Contents
  • U436-06N-G-C USB 3.1 Gen 1 USB-C to Gigabit Ethernet NIC Network Adapter
  • Owner's Manual
Device Supported Notebook
Device Supported Tablet
Device Supported Computer
Environmentally Friendly Yes
Country of Origin Vietnam
Limited Warranty 3 Year
