MARKETING INFORMATION

This USB 3.2 Gen 2 card prepares you for the next generation of USB performance, on the inside and outside of your computer. The 2-port card adds one internal Type-A connector as well as one external Type-A connector to your desktop computer, with a combined bandwidth of up to 10Gbps. For power-hungry devices, the card also has an internal SATA power connector, enabling you to use your computer's power supply to add more power to the ports.
With greater bandwidth, you can save time and avoid the performance bottlenecks that are often associated with other connectivity technologies.
With an internal port, you can connect internal devices that use a USB Type-A connector, such as a front-bay SD card reader. Plus, you can use the internal port to keep peripherals safely inside your computer case - perfect for high-capacity USB flash drives or interface devices used for external wireless peripherals such as keyboards and mice or Bluetooth adapters.
The card also features an external port that can be used for any USB Type-A device, like your external hard drive or any wired peripheral.
By adding 10Gbps USB ports to your computer, you can harness the speed of USB 3.2 Gen 2 and rest assured that you're ready for both current and future high-bandwidth USB-A devices.
With higher data throughput, this PCI Express USB 3.2 card is a necessity for external hard drives, , and many other USB 3.2 peripherals. Plus, the USB card integrates a SATA power connector to support high-powered devices, making it ideal for use with large external storage solutions.
For more flexibility, you can couple the card with a USB-C to USB-A cable (USB31AC1M) and connect your USB Type-C devices.
Connecting your older peripherals isn't a problem. This versatile USB 3.2 Gen 2 (10Gbps) card is backward compatible with legacy USB 3.2 Gen 1 and 2.0 devices that use the common USB Type-A port, so you can eliminate the added expense and aggravation of purchasing new devices.
For a hassle-free installation with no additional software or drivers required, the card is natively supported by most operating systems, and interfaces with the PCI Express 3.0 x4 slot on your computer. Plus, the high-quality card includes both standard-profile and low-profile (half-height) brackets, making it easy to install in full or small form-factor PCs or servers.
The PEXUSB311EI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

More from the Manufacturer

DETAILS

• Host Interface : PCI Express x4
• UASP Support : Yes
• Total Number of USB Ports : 2
• Number of USB 3.2 Ports : 2
• Number of SATA Ports : 1
• Operating System Supported : Windows 7,Windows 8,Windows 8.1,Windows 10,Windows 11,Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019,Mac OS X 10.10 Yosemite,Linux 4.11.x
• Color Family : Black
• Product Color : Black
• Form Factor : Plug-in Card
• Height : 4.70" (119.38 mm)
• Width : 0.70" (17.78 mm)
• Length : 3.50" (88.90 mm)
• Weight (Approximate) : 1.80 oz (51.03 g)
• Package Contents :
  • 2-Port USB 3.1 (10Gbps) Card - USB-A, 1x External, 1x Internal - PCIe
  • 1 x Low-profile Bracket
  • 1 x Instruction Manual
• Platform Supported : PC,Mac,Linux
• Country of Origin : China
• Environmentally Friendly : Yes
• Limited Warranty : 2 Year

• Transfer files and access USB 3.1 devices faster, both inside and outside your computer case, with up to 10Gbps throughput
• Fast, hassle-free setup, and natively supported by many operating systems
• Fits into standard or low-profile systems, with its dual-profile design
• Cost-effective backward compatibility
• Compatible with high-powered USB devices, with an integrated SATA power connector
• Compliant with UASP (USB Attached SCSI Protocol) Revision 1.0
• Compliant with Universal Serial Bus 3.1 Specification Revision 1.0, and Universal Serial Bus Specification Revision 2.0
• PCIe x4 interface compliant with PCI Express Base Specification Revision 3.0
• Equipped with a full-profile bracket, includes a low-profile (half-height) bracket for installation in small form-factor computers
