CyberPower UPS Systems RMCARD205 Hardware - Supported Protocols: TCP/IP, UDP, FTP, SCP, DHCP, DNS, SSH, Telnet, HTTP/HTTPS, SNMPv1/v3, IPv4/v6, NTP, SMTP, and Syslog - 2 x Network (RJ-45) Port(s)

RMCARD205
Also known as SY5523556,DHRMCARD205CA

New! Log in or create an account to see price and availability


MARKETING INFORMATION

A full-featured network management card, the CyberPower RMCARD205 remotely manages, monitors and controls select CyberPower UPS systems and ATS PDUs via a standard web browser, command line interface (CLI), SNMP or network management system (NMS). Especially suited to enterprise installations, the RMCARD205 provides scheduling for UPS shutdown, startup, and rebooting, along with event action settings, event logging, status recording, and automatic event notifications via email, SMS, SNMP traps, or Syslog. PowerPanel® Business Edition Client software protects servers and workstations from data loss due to power failure by initiating auto-shutdown command from a UPS when a power loss event occurs.

DETAILS

  • Protocols : TCP/IP,UDP,FTP,DHCP,DNS,SSH,Telnet,HTTP,HTTPS,SNMPv3,SNMP v1,IPv4,IPv6,NTP,SMTP,SSL,RADIUS,LDAP,LDAPS,TLS,Syslog
  • Network (RJ-45) : Yes
  • Number of Network (RJ-45) Ports : 2
  • Ethernet Technology : Fast Ethernet
  • Color Family : Black
  • Product Color : Black
  • Height : 1.42" (36.07 mm)
  • Width : 2.13" (54.10 mm)
  • Depth : 3" (76.20 mm)
  • Weight (Approximate) : 1.28 oz (36.29 g)
  • Package Contents :
    • RMCARD205 UPS & ATS PDU Remote Management Card - SNMP/HTTP/NMS/Enviro Port
    • Quick Start Guide
    • Spare Jumper
  • Country of Origin : China
  • Environmentally Friendly : Yes
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Limited Warranty : 3 Year
  • Supported Protocols: TCP/IP, UDP, FTP, SCP, DHCP, DNS, SSH, Telnet, HTTP/HTTPS, SNMPv1/v3, IPv4/v6, NTP, SMTP, and Syslog
  • Remote management: Web browser, CLI, SNMP or NMS
  • Auto shutdown: Workstations, multiple servers
  • Auto shutdown clients: 50
  • Auto event notification: Email, SMS, SNMP Traps, Syslog
  • Remote scheduling: Shutdown, startup, reboot
  • Ethernet speeds: 10/100 Mbps
  • Environmental Sensor compatible: Yes
  • Upgradable firmware: Yes, via FTP or SCP
  • Warranty: 3 year

SPECIFICATIONS

Manufacturer CyberPower Systems, Inc
Manufacturer Part Number RMCARD205
Manufacturer Website Address https://www.cyberpowersystems.com/
Brand Name CyberPower
Product Series UPS Hardware
Product Model RMCARD205
Product Name RMCARD205 UPS & ATS PDU Remote Management Card - SNMP/HTTP/NMS/Enviro Port
Product Type Remote Power Management Adapter
Protocols HTTPS
Protocols SNMP v1
Protocols IPv4
Protocols IPv6
Protocols NTP
Protocols SMTP
Protocols SSL
Protocols RADIUS
Protocols LDAP
Protocols LDAPS
Protocols TLS
Protocols Syslog
Protocols HTTP
Protocols Telnet
Protocols SSH
Protocols DNS
Protocols DHCP
Protocols FTP
Protocols UDP
Protocols TCP/IP
Protocols SNMPv3
Network (RJ-45) Yes
Number of Network (RJ-45) Ports 2
Ethernet Technology Fast Ethernet
Color Family Black
Product Color Black
Height 1.42" (36.07 mm)
Width 2.13" (54.10 mm)
Depth 3" (76.20 mm)
Weight (Approximate) 1.28 oz (36.29 g)
Package Contents
  • RMCARD205 UPS & ATS PDU Remote Management Card - SNMP/HTTP/NMS/Enviro Port
  • Quick Start Guide
  • Spare Jumper
Additional Information
  • Data Link Protocol : Ethernet 100Base-TX, Ethernet 10Base-T
  • Network Protection RJ45 : Ethernet RJ45
  • LED Indicators : Tx/Rx
  • Operating Elevation : 0 - 10000 ft (0 - 3048 m)
  • Operating Relative Humidity : 0 - 90 % (non-condensing)
  • Operating Temperature : 32 - 104 °F (0 - 40 °C)
  • Storage Elevation : 0 - 50000 ft (0 - 15239 m)
  • Storage Relative Humidity : 0 - 95% (non-condensing)
  • Storage Temperature : 14 - 122 °F (-10 - 50 °C)
  • Safety : FCC DoC Class , CE
Protocols:
  • Cisco EnergyWise : v1.2.0 and newer
  • DHCP : RFC 2131
  • DNS : RFC 1035
  • FTP : RFC 959
  • HTTP : v1.1: RFC 2616
  • HTTPS : RFC 2818
  • LDAP : v3: RFC 2251
  • LDAPS : v3: RFC 4513
  • MIB : RFC 1213, RFC 1628
  • NTP : RFC 958
  • RADIUS : RFC 2865
  • SCP : v2: RFC 4253, RFC 4254
  • SMTP : RFC 2821
  • SMTPS : RFC 3207
  • SNMP : v1: RFC 1155, RFC 1156, RFC 1157
  • SSH : v2: RFC 4253, RFC 4254
  • SSL : v3: RFC 6101
  • SysLog : RFC 5424
  • TCP/IP : v4: RFC 791
  • Telnet : RFC 854
  • TLS : v1: RFC 2246
Compatibility
  • OL1000RTXL2U
  • OL1500RTXL2U
  • OL1500RTXL2UN
  • OL2200RTXL2U
  • OL3000RTXL2U
  • OL3000RTXL2UHV
  • PR500LCDRT1U
  • PR750LCD
  • PR1500LCDN
  • PR750LCDRM1U
  • PR750LCDRT1U
  • PR750LCDRTXL2U
  • PR1000LCD
  • PR1000LCDRM1U
  • PR1000LCDRT1U
  • PR1000LCDRT2U
  • PR1000LCDRTXL2U
  • PR1000LCDRTXL2Ua
  • PR1500LCD
  • PR1500LCDRT2U
  • PR1500LCDRT2UN
  • PR1500LCDRTXL2U
  • PR1500LCDRTXL2UN
  • PR1500LCDRTXL2Ua
  • PR2200LCD
  • PR2200LCDSL
  • PR2200LCDRT2U
  • PR2200LCDRT2UN
  • PR2200LCDRTXL2U
  • PR3000LCD
  • PR3000LCDSL
  • PR3000LCDRT2U
  • PR3000LCDRTXL2U
  • PR3000LCDRTXL2UN
  • PR5000LCDRTXL5U
  • PR6000LCDRTXL5U
  • OR500LCDRM1U
  • OR700LCDRM1U
  • OR1000LCDRM1U
  • OR1500LCDRM1U
  • OR1500LCDRM2U
  • OR1500LCDRT2U
  • OR1500LCDRTXL2U
  • OR2200LCDRM2U
  • OR2200LCDRT2U
  • OR2200LCDRTXL2U
  • CPS1500AVR
  • PDU15M10AT
  • PDU20M10AT
  • PDU20MT10AT
  • PDU30MT17AT
  • PDU15MHVIEC12AT
  • PDU20MHVT10AT
  • PDU20MHVIEC10AT
  • PDU30MHVT19AT
  • PDU15SW10ATNET
  • PDU20SW10ATNET
  • PDU20SWT10ATNET
  • PDU30SWT17ATNET
  • PDU15SWHVIEC12ATNET
  • PDU20SWHVT10ATNET
  • PDU20SWHVIEC10ATNET
  • PDU30SWHVT19ATNET
Country of Origin China
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Limited Warranty 3 Year
