MARKETING INFORMATION

Complete remote server management

The ASMB8-iKVM (IPMI 2.0-compliant) enables remote update BIOS, standalone KVM/Java utility, video recording and BSOD capture. Based on out-of-band management, even if the server operating system is down or offline, the KVM module can still provide round-the-clock remote monitoring and diagnosis through a user-friendly web-based graphical interface via all major browsers. In addition, ASWM Enterprise software provides one-to-multiple centralized management including BIOS flash, software dispatch, task scheduler, remote control, and power control, all through a colorful and informative graphical interface. Through ASUS remote management solution, user could save time and effort on server management and trouble-shooting.

DETAILS

• Number of Processors Supported : 2
• Processor Socket : Socket LGA 2011-v3
• Processor Supported : Xeon
• 64-bit Processing : Yes
• Chipset Manufacturer : Intel
• Chipset Model : C612
• Maximum Memory Supported : 1.50 TB
• Memory Technology : DDR4 SDRAM
• Memory Standard : DDR4-2133/PC4-17000
• Total Number of Memory Slots : 24
• Controller Type : Serial ATA/600
• RAID Supported : Yes
• Graphics Controller Model : AST2400
• Graphics Memory Capacity : 32 MB
• Ethernet Technology : Gigabit Ethernet
• Number of Total Expansion Bays : 6
• Total Number of Expansion Slots : 10
• Number of PCI Express x8 Slots : 1
• Number of PCI Express x16 Slots : 9
• Total Number of USB Ports : 4
• Number of USB 3.0 Ports : 2
• Number of SATA Interfaces : 6
• Operating System Supported : Windows Server 2012 R2,Windows Server 2012,Windows Server 2008 R2 Enterprise,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,CentOS,Ubuntu Linux
• Number of Power Supplies Installed : 3
• Maximum Power Supply Wattage : 1.60 kW
• Form Factor : Rack-mountable
• Rack Height : 3U
• Height : 5.14" (130.60 mm)
• Width : 17.60" (447 mm)
• Depth : 29.88" (759 mm)
• Weight (Approximate) : 64.37 lb (29200 g)
• Environmentally Friendly : Yes

• Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
• DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
• Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
• Provides 4 USB ports for responsive and expanded device connections
• With Serial ATA/600 interface get superb reliability and high-speed data transfer
