Lenovo PureFlex System x240 87374MU Blade Server - 1 Xeon E5-2650 v2 2.60 GHz - 8 GB RAM - Serial ATA/600, 6Gb/s SAS Controller - Intel C600 Chip - 2 Processor Support - DDR3 SDRAM - 0, 1, 1E RAID Levels - G200eR2 Up to 16 MB Graphic Card - 10 Gigabit Ethernet - 2 x SFF Bay(s)

87374MU
Also known as SY5353228

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The IBM® Flex System™ x240 Compute Node is a high-performance server that offers outstanding performance for virtualization with new levels of CPU performance and memory capacity, and flexible configuration options. Now available with Intel Xeon E5-2600 v2 processors, the x240 Compute Node is an efficient server designed to run a broad range of workloads, armed with advanced management capabilities that allow you to manage your physical and virtual IT resources from a single pane of glass. This IBM Redbooks® Product Guide describes the IBM Flex System x240 Compute Node.

DETAILS

  • Number of Processors Supported : 2
  • Number of Processors Installed : 1
  • Processor Type : Xeon
  • Processor Model : E5-2650 v2
  • Processor Core : Octa-core (8 Core)
  • Processor Speed : 2.60 GHz
  • Cache : 20 MB
  • Chipset Manufacturer : Intel
  • Chipset Model : C600
  • Standard Memory : 8 GB
  • Memory Technology : DDR3 SDRAM
  • Total Number of Memory Slots : 24
  • Controller Type : Serial ATA/600,6Gb/s SAS
  • RAID Supported : Yes
  • RAID Levels : 0, 1, 1E
  • Number of Total Expansion Bays : 2
  • Number of Internal 2.5" Bays : 2
  • Total Number of Expansion Slots : 2
  • Graphics Controller Model : G200eR2
  • Graphics Memory Capacity : 16 MB
  • Ethernet Technology : 10 Gigabit Ethernet
  • Total Number of USB Ports : 1
  • Network (RJ-45) : Yes
  • Remote Management : Yes
  • Operating System : No
  • Package Contents :
    • PureFlex System x240 87374MU Server
    • Statement of Limited Warranty
    • Important Notices
    • Documentation CD that contains the Installation and User's Guide
  • Form Factor : Blade
  • Height : 2.20" (55.88 mm)
  • Width : 8.60" (218.44 mm)
  • Depth : 19.40" (492.76 mm)
  • Weight (Approximate) : 15.65 lb (7100 g)
  • Limited Warranty : 3 Year
  • Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.60 GHz processor
  • With 8 GB memory, improve system performance to execute complex applications
  • RAID provides data reliability, fault tolerance and improves overall performance through RAID levels (0, 1, 1E)
  • Optimize the performance of business networks with 10 Gigabit Ethernet connectivity

SPECIFICATIONS

Manufacturer Lenovo Group Limited
Manufacturer Part Number 87374MU
Manufacturer Website Address http://www.lenovo.com
Brand Name Lenovo
Product Line PureFlex System
Product Series x240
Product Model 87374MU
Product Name PureFlex System x240 87374MU Server
Product Type Server
Number of Processors Supported 2
Number of Processors Installed 1
Processor Type Xeon
Processor Model E5-2650 v2
Processor Core Octa-core (8 Core)
Processor Speed 2.60 GHz
Maximum Turbo Speed 3.40 GHz
Cache 20 MB
QuickPath Interconnect 8 GT/s
64-bit Processing Yes
Hyper-Threading Yes
Chipset Manufacturer Intel
Chipset Model C600
Standard Memory 8 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1866/PC3-14900
Total Number of Memory Slots 24
Controller Type 6Gb/s SAS
Controller Type Serial ATA/600
RAID Supported Yes
RAID Levels 0, 1, 1E
Number of Total Expansion Bays 2
Number of Internal 2.5" Bays 2
Total Number of Expansion Slots 2
Number of PCI Express x16 Slots 2
Graphics Controller Model G200eR2
Graphics Memory Capacity 16 MB
Ethernet Technology 10 Gigabit Ethernet
Total Number of USB Ports 1
Network (RJ-45) Yes
Remote Management Yes
Operating System No
Form Factor Blade
Height 2.20" (55.88 mm)
Width 8.60" (218.44 mm)
Depth 19.40" (492.76 mm)
Weight (Approximate) 15.65 lb (7100 g)
Package Contents
  • PureFlex System x240 87374MU Server
  • Statement of Limited Warranty
  • Important Notices
  • Documentation CD that contains the Installation and User's Guide
Compatibility
  • Microsoft Windows Server 2008 HPC Edition
  • Microsoft Windows Server 2008 R2
  • Microsoft Windows Server 2008, Datacenter x64 Edition
  • Microsoft Windows Server 2008, Enterprise x64 Edition
  • Microsoft Windows Server 2008, Standard x64 Edition
  • Microsoft Windows Server 2008, Web x64 Edition
  • Microsoft Windows Server 2012
  • Red Hat Enterprise Linux 5 Server with Xen x64 Edition
  • Red Hat Enterprise Linux 5 Server x64 Edition
  • Red Hat Enterprise Linux 6 Server x64 Edition
  • SUSE Linux Enterprise Server 11 for AMD64/EM64T
  • SUSE Linux Enterprise Server 11 with Xen for AMD64/EM64T
  • VMware vSphere 5.0 (ESXi)
  • VMware vSphere 5.1 (ESXi)
Certifications & Standards
  • ASHRAE Class A3
  • FCC - Verified to comply with Part 15 of the FCC Rules Class A
  • Canada ICES-004, issue 3 Class A
  • UL/IEC 60950-1
  • CSA C22.2 No. 60950-1
  • NOM-019
  • Argentina IEC 60950-1
  • Japan VCCI, Class A
  • IEC 60950-1 (CB Certificate and CB Test Report)
  • China CCC (GB4943); (GB9254, Class A); (GB17625.1)
  • Taiwan BSMI CNS13438, Class A; CNS14336
  • Australia/New Zealand AS/NZS CISPR 22, Class A
  • Korea KN22, Class A, KN24
  • Russia/GOST ME01, IEC 60950-1, GOST R 51318.22, GOST R
  • 51318.249, GOST R 51317.3.2, GOST R 51317.3.3
  • IEC 60950-1 (CB Certificate and CB Test Report)
  • CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2,
  • EN61000-3-3)
  • CISPR 22, Class A
  • TUV-GS (EN60950-1/IEC 60950-1, EK1-ITB2000)
Limited Warranty 3 Year
