Lenovo Flex System x440 7917C2U Server - 2 Xeon E5-4610 2.40 GHz - 8 GB RAM - Serial ATA/600, 6Gb/s SAS Controller - Intel C600 Chip - 4 Processor Support - 384 GB RAM Support - DDR3 SDRAM - 0, 1, 10, 1E RAID Levels - G200eR2 Up to 16 MB Graphic Card - 2 x SFF Bay(s)
7917C2U
Also known as SY5353200
MARKETING INFORMATION
A building block for the IBM PureFlex System family, the IBM Flex System™ x440 Compute Node is a four-socket Intel Xeon processor-based server optimized for high-end virtualization, mainstream database deployments, and memory-intensive high performance environments. It is price-performance optimized with a wide range of processors, memory, and I/O options to help you match system capabilities and cost to workloads without compromise. With a dense design, the Flex System x440 Compute Node can help reduce floor space used, and lower data center power and cooling costs.DETAILS
- Number of Processors Supported : 4
- Number of Processors Installed : 2
- Processor Type : Xeon
- Processor Model : E5-4610
- Processor Core : Hexa-core (6 Core)
- Processor Speed : 2.40 GHz
- Cache : 15 MB
- Chipset Manufacturer : Intel
- Chipset Model : C600
- Standard Memory : 8 GB
- Maximum Memory Supported : 384 GB
- Memory Technology : DDR3 SDRAM
- Total Number of Memory Slots : 48
- Controller Type : Serial ATA/600,6Gb/s SAS
- RAID Supported : Yes
- RAID Levels : 0, 1, 10, 1E
- Number of Total Expansion Bays : 2
- Number of Internal 2.5" Bays : 2
- Total Number of Expansion Slots : 4
- Graphics Controller Model : G200eR2
- Graphics Memory Capacity : 16 MB
- Total Number of USB Ports : 3
- Remote Management : Yes
- Operating System : No
- Package Contents :
- Flex System x440 7917C2U Server
- Statement of Limited Warranty
- Important Notices
- Documentation CD that contains the Installation and Service Guide
- Height : 2" (50.80 mm)
- Width : 17.20" (436.88 mm)
- Depth : 19.40" (492.76 mm)
- Weight (Approximate) : 27.01 lb (12250 g)
- Limited Warranty : 3 Year
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.40 GHz processor
- With 8 GB memory, improve system performance to execute complex applications
- RAID provides data reliability, fault tolerance and improves overall performance
SPECIFICATIONS
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7917C2U |
| Manufacturer Website Address | http://www.lenovo.com |
| Brand Name | Lenovo |
| Product Line | Flex System |
| Product Series | x440 |
| Product Model | 7917C2U |
| Product Name | Flex System x440 7917C2U Server |
| Product Type | Server |
| Number of Processors Supported | 4 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon |
| Processor Model | E5-4610 |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 2.40 GHz |
| Cache | 15 MB |
| QuickPath Interconnect | 7.20 GT/s |
| 64-bit Processing | Yes |
| Hyper-Threading | Yes |
| Chipset Manufacturer | Intel |
| Chipset Model | C600 |
| Standard Memory | 8 GB |
| Maximum Memory Supported | 384 GB |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-1333/PC3-10600 |
| Total Number of Memory Slots | 48 |
| Controller Type | 6Gb/s SAS |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 10, 1E |
| Number of Total Expansion Bays | 2 |
| Number of Internal 2.5" Bays | 2 |
| Total Number of Expansion Slots | 4 |
| Number of PCI Express x16 Slots | 4 |
| Graphics Controller Model | G200eR2 |
| Graphics Memory Capacity | 16 MB |
| Total Number of USB Ports | 3 |
| Remote Management | Yes |
| Operating System | No |
| Height | 2" (50.80 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 19.40" (492.76 mm) |
| Weight (Approximate) | 27.01 lb (12250 g) |
| Package Contents |
|
| Compatibility |
|
| Certifications & Standards |
|
| Limited Warranty | 3 Year |
