Lenovo Flex System x222 7916H6U Server - 2 Xeon E5-2430 2.20 GHz - 16 GB RAM - Serial ATA Controller - Intel C600 Chip - 4 Processor Support - 192 GB RAM Support - DDR3 SDRAM - G200eR2 Up to 16 MB Graphic Card - 10 Gigabit Ethernet - 2 x SFF Bay(s)
7916H6U
Also known as SY5353192
MARKETING INFORMATION
The IBM® Flex System™ x222 Compute Node is a high-density dual-server offering that is designed for virtualization, dense cloud deployments, and hosted clients. The x222 has two independent servers in one mechanical package, which means that the x222 has a double-density design that allows up to 28 servers to be housed in a single 10U Flex System Enterprise Chassis.DETAILS
- Number of Processors Supported : 4
- Number of Processors Installed : 2
- Processor Type : Xeon
- Processor Model : E5-2430
- Processor Core : Hexa-core (6 Core)
- Processor Speed : 2.20 GHz
- Cache : 15 MB
- Chipset Manufacturer : Intel
- Chipset Model : C600
- Standard Memory : 16 GB
- Maximum Memory Supported : 192 GB
- Memory Technology : DDR3 SDRAM
- Total Number of Memory Slots : 24
- Optical Drive Type : No
- Controller Type : Serial ATA
- RAID Supported : No
- Number of Total Expansion Bays : 2
- Number of Internal 2.5" Bays : 2
- Total Number of Expansion Slots : 1
- Graphics Controller Model : G200eR2
- Graphics Memory Capacity : 16 MB
- Ethernet Technology : 10 Gigabit Ethernet
- Total Number of USB Ports : 3
- Network (RJ-45) : Yes
- Remote Management : Yes
- Operating System : No
- Height : 2.20" (55.88 mm)
- Width : 8.60" (218.44 mm)
- Depth : 19.40" (492.76 mm)
- Weight (Approximate) : 18.08 lb (8200 g)
- Limited Warranty : 3 Year
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.20 GHz processor
- With 16 GB memory, improve system performance to execute complex applications
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
SPECIFICATIONS
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7916H6U |
| Manufacturer Website Address | http://www.lenovo.com |
| Brand Name | Lenovo |
| Product Line | Flex System |
| Product Series | x222 |
| Product Model | 7916H6U |
| Product Name | Flex System x222 7916H6U Server |
| Product Type | Server |
| Number of Processors Supported | 4 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon |
| Processor Model | E5-2430 |
| Processor Core | Hexa-core (6 Core) |
| Processor Speed | 2.20 GHz |
| Cache | 15 MB |
| QuickPath Interconnect | 7.20 GT/s |
| 64-bit Processing | Yes |
| Hyper-Threading | Yes |
| Chipset Manufacturer | Intel |
| Chipset Model | C600 |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 192 GB |
| Memory Technology | DDR3 SDRAM |
| Memory Standard | DDR3-1333/PC3-10600 |
| Total Number of Memory Slots | 24 |
| Optical Drive Type | No |
| Controller Type | Serial ATA |
| RAID Supported | No |
| Number of Total Expansion Bays | 2 |
| Number of Internal 2.5" Bays | 2 |
| Total Number of Expansion Slots | 1 |
| Number of PCI Express x16 Slots | 1 |
| Graphics Controller Model | G200eR2 |
| Graphics Memory Capacity | 16 MB |
| Ethernet Technology | 10 Gigabit Ethernet |
| Total Number of USB Ports | 3 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Operating System | No |
| Height | 2.20" (55.88 mm) |
| Width | 8.60" (218.44 mm) |
| Depth | 19.40" (492.76 mm) |
| Weight (Approximate) | 18.08 lb (8200 g) |
| Package Contents |
|
| Compatibility |
|
| Certifications & Standards |
|
| Limited Warranty | 3 Year |
