Lenovo Flex System x220 7906G4U Server - 1 Xeon E5-2430 2.20 GHz - 4 GB RAM - Serial ATA/600 Controller - Intel C600 Chip - 2 Processor Support - 96 GB RAM Support - DDR3 SDRAM - 0, 1 RAID Levels - G200eR2 Up to 16 MB Graphic Card - Gigabit Ethernet - 2 x SFF Bay(s)

7906G4U
Also known as SY5353106

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The IBM Flex System x220 Compute Node is the next generation cost-optimized compute node designed for less demanding workloads and low-density virtualization. The x220 is efficient and equipped with flexible configuration options and advanced management to run a broad range of workloads.

DETAILS

  • Number of Processors Supported : 2
  • Number of Processors Installed : 1
  • Processor Type : Xeon
  • Processor Model : E5-2430
  • Processor Core : Hexa-core (6 Core)
  • Processor Speed : 2.20 GHz
  • Cache : 15 MB
  • Chipset Manufacturer : Intel
  • Chipset Model : C600
  • Standard Memory : 4 GB
  • Maximum Memory Supported : 96 GB
  • Memory Technology : DDR3 SDRAM
  • Total Number of Memory Slots : 12
  • Controller Type : Serial ATA/600
  • RAID Supported : Yes
  • RAID Levels : 0, 1
  • Number of Total Expansion Bays : 2
  • Number of Internal 2.5" Bays : 2
  • Total Number of Expansion Slots : 2
  • Graphics Controller Model : G200eR2
  • Graphics Memory Capacity : 16 MB
  • Ethernet Technology : Gigabit Ethernet
  • Total Number of USB Ports : 3
  • Network (RJ-45) : Yes
  • Remote Management : Yes
  • Operating System : No
  • Package Contents :
    • Flex System x220 7906G4U Server
    • Statement of Limited Warranty
    • Important Notices
    • Documentation CD that contains the Installation and User's Guide
  • Height : 2.20" (56 mm)
  • Width : 8.54" (217 mm)
  • Depth : 19.37" (492 mm)
  • Weight (Approximate) : 14.11 lb (6400 g)
  • Limited Warranty : 3 Year
  • Experience high performance, built-in security and remote management capabilities with Intel Xeon 2.20 GHz processor
  • 4 GB memory is great for multitasking
  • Gigabit Ethernet port for ultra-fast network speeds

SPECIFICATIONS

Manufacturer Lenovo Group Limited
Manufacturer Part Number 7906G4U
Manufacturer Website Address http://www.lenovo.com
Brand Name Lenovo
Product Line Flex System
Product Series x220
Product Model 7906G4U
Product Name Flex System x220 7906G4U Server
Product Type Server
Number of Processors Supported 2
Number of Processors Installed 1
Processor Type Xeon
Processor Model E5-2430
Processor Core Hexa-core (6 Core)
Processor Speed 2.20 GHz
Cache 15 MB
QuickPath Interconnect 7.20 GT/s
64-bit Processing Yes
Hyper-Threading Yes
Chipset Manufacturer Intel
Chipset Model C600
Standard Memory 4 GB
Maximum Memory Supported 96 GB
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1333/PC3-10600
Total Number of Memory Slots 12
Controller Type Serial ATA/600
RAID Supported Yes
RAID Levels 0, 1
Number of Total Expansion Bays 2
Number of Internal 2.5" Bays 2
Total Number of Expansion Slots 2
Graphics Controller Model G200eR2
Graphics Memory Capacity 16 MB
Ethernet Technology Gigabit Ethernet
Total Number of USB Ports 3
Network (RJ-45) Yes
Remote Management Yes
Operating System No
Height 2.20" (56 mm)
Width 8.54" (217 mm)
Depth 19.37" (492 mm)
Weight (Approximate) 14.11 lb (6400 g)
Package Contents
  • Flex System x220 7906G4U Server
  • Statement of Limited Warranty
  • Important Notices
  • Documentation CD that contains the Installation and User's Guide
Compatibility
  • Microsoft Windows Server 2008 HPC Edition
  • Microsoft Windows Server 2008 R2
  • Microsoft Windows Server 2008, Datacenter x64 Edition
  • Microsoft Windows Server 2008, Enterprise x64 Edition
  • Microsoft Windows Server 2008, Standard x64 Edition
  • Microsoft Windows Server 2008, Web x64 Edition
  • Red Hat Enterprise Linux 5 Server with Xen x64 Edition
  • Red Hat Enterprise Linux 5 Server x64 Edition
  • Red Hat Enterprise Linux 6 Server x64 Edition
  • SUSE LINUX Enterprise Server 10 for AMD64/EM64T
  • SUSE LINUX Enterprise Server 11 for AMD64/EM64T
  • SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T
  • VMware ESX 4.1
  • VMware ESXi 4.1
  • VMware vSphere 5
  • VMware vSphere 5.1
Certifications & Standards
  • ASHRAE Class A3
  • FCC - Verified to comply with Part 15 of the FCC Rules Class A
  • Canada ICES-004, issue 3 Class A
  • UL/IEC 60950-1
  • CSA C22.2 No. 60950-1
  • NOM-019
  • Argentina IEC 60950-1
  • Japan VCCI, Class A
  • IEC 60950-1 (CB Certificate and CB Test Report)
  • China CCC (GB4943); (GB9254, Class A); (GB17625.1)
  • Taiwan BSMI CNS13438, Class A; CNS14336
  • Australia/New Zealand AS/NZS CISPR 22, Class A
  • Korea KN22, Class A, KN24
  • Russia/GOST ME01, IEC 60950-1, GOST R 51318.22, GOST R
  • 51318.249, GOST R 51317.3.2, GOST R 51317.3.3
  • IEC 60950-1 (CB Certificate and CB Test Report)
  • CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2, and
  • EN61000-3-3)
  • CISPR 22, Class A
  • TUV-GS (EN60950-1/IEC 60950-1, EK1-ITB2000)
Limited Warranty 3 Year
