Ergotron Mounting Arm for Flat Panel Display - Polished Aluminum, Black - 30" to 55" Screen Support - 40 lb (18143.69 g) Load Capacity - 200 x 100, 200 x 400 - VESA Mount Compatible

45-296-026
Also known as SY4780918

New! Log in or create an account to see price and availability


MARKETING INFORMATION

Accommodate the active TV positioning needs of today and tomorrow. Lift, swing or turn your display in any direction! Features 20 inches (51 cm) of vertical adjustment and 17.5-inch (45 cm) motion adjustment to either side.

Now anyone can effortlessly move their TV into multiple positions with only a light touch. Your screen will seemingly float on air, being easily adjusted between standing and seated heights. No more awkward viewing angles and sore necks.

DETAILS

  • Device Supported : Flat Panel Display
  • Maximum Load Capacity : 40 lb (18143.69 g)
  • Minimum Screen Size Supported : 30"
  • Maximum Screen Size Supported : 55"
  • Features : Tilt,Pan,Swivel,Cable Management
  • Product Color : Polished Aluminum,Black
  • VESA Mount Compatible : Yes
  • Mounting Pattern : 200 x 100,200 x 400
  • Package Contents :
    • HD Interactive Arm
    • Wall Mount Bracket
    • VESA Adapter Brackets
    • Complete Hardware Kit
  • Compatibility :

    LCD Screen

  • Country of Origin : China
  • Limited Warranty : 5 Year
  • Sustains a maximum load capacity of 40 lb (18143.69 g)
  • Supports 55" displays

SPECIFICATIONS

Manufacturer Ergotron, Inc
Manufacturer Part Number 45296026
Manufacturer Website Address http://www.ergotron.com
Brand Name Ergotron
Product Name HD Interactive Arm
Product Type Mounting Arm
Device Supported Flat Panel Display
Maximum Load Capacity 40 lb (18143.69 g)
Minimum Screen Size Supported 30"
Maximum Screen Size Supported 55"
Features Swivel
Features Pan
Features Tilt
Features Cable Management
Product Color Polished Aluminum
Product Color Black
VESA Mount Compatible Yes
Mounting Pattern 200 x 400
Mounting Pattern 200 x 100
Package Contents
  • HD Interactive Arm
  • Wall Mount Bracket
  • VESA Adapter Brackets
  • Complete Hardware Kit
Additional Information
  • Lift: 20"
  • Tilt: 25°
  • Pan: 180°
  • Rotation: 10°
  • Patented Constant Force technology enables light-touch adjustments
  • Extends 24" from wall when in use and can be fully retracted to 5.5" when not in use
  • Provides smooth, continuous vertical and horizontal movement of the TV/display in all directions
  • Gravity pivot enables tilting capabilities without the need of knobs or levers
  • Improves ergonomic viewing for TVs/displays mounted high on the wall
  • Tilt and pan for maximum viewing flexibility
  • Level the screen at any position with +/- 5ยบ of post-installation rotation
  • Cable management clips on the underside of the arm route and hide wires
  • Easy to use: simple installation and effortless operation
Compatibility

LCD Screen

Certifications & Standards

VESA MIS-E/F

Country of Origin China
Limited Warranty 5 Year
