CyberPower PR5000LCDRTXL5U Smart App Sinewave UPS Systems - 5000VA/4500W, 208 VAC, NEMA L6-30P, 5U, Rack / Tower, Sine Wave, 5 Outlets, LCD, PowerPanel® Business, $300000 CEG, 3YR Warranty

PR5000LCDRTXL5U
Also known as SY4754804

New! Log in or create an account to see price and availability


MARKETING INFORMATION

A rack/tower convertible UPS with line interactive topology, the CyberPower Smart App Sinewave PR5000LCDRTXL5U provides battery backup, power protection (using sine wave output), and surge protection for corporate servers, department servers, storage appliances, network devices, and telecom installations requiring Active PFC power source compatibility. The PR5000LCDRTXL5U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The PR5000LCDRTXL5U comes with a three-year warranty (including coverage of batteries) and a $300,000 Connected Equipment Guarantee.

DETAILS

  • AVR : Yes
  • Plug/Connector Type : NEMA L6-30P
  • Receptacle Type : NEMA L6-20R,NEMA L6-30R
  • Receptacle Detail : 3 x NEMA L6-30R,2 x NEMA L6-20R
  • Number of Battery & Surge Outlets : 5
  • Number of Critical Load Outlets : 2
  • Dataline Protection : Coax,RJ-11/RJ-45
  • Overload Protection : Yes
  • Cord Length : 10 ft (3.05 m)
  • Transfer Time : 4 ms
  • EMI/RFI Noise Filter : Yes
  • Energy Saving : GreenPower UPS™ Bypass Technology
  • Application/Usage : Corporate,Server,Storage,Network Device,Telecommunication,Mission Critical Equipment,VoIP,Workstation
  • Surge Suppression : Yes
  • Features : Cold Start Function,Audible Alarm,Auto Restart,Self Test,Auto Charge
  • Load Capacity (VA) : 5 kVA
  • Load Capacity (Watt) : 4.50 kW
  • Input Voltage : 230 V AC
  • Input Voltage Range : 208 V AC - 240 V AC,131 V AC - 268 V AC,148 V AC - 254 V AC
  • Output Voltage : 208 V AC
  • Input Frequency : 63 Hz,47 Hz
  • Output Frequency : 60 Hz,50 Hz
  • Waveform Type : Sine Wave
  • Surge Energy Rating : 2430 J
  • Circuit Breaker : Yes
  • Output Power Factor : 0.9
  • Display : LCD
  • Network Management : SNMP/HTTP Remote Monitoring,Relay-MS Card
  • Alarm : Battery Mode,Low Battery,Overload
  • Serial Port : Yes
  • USB : Yes
  • Network (RJ-45) : Yes
  • EPO Port : Yes
  • USB (HID Compliant) Port : Yes
  • Number of Batteries : 16
  • Battery Characteristics : Sealed
  • Battery Chemistry : Lead Acid
  • Battery Size : 12V
  • Battery Capacity : 9000 mAh
  • Backup/Run Time (Full Load) : 10 Minute
  • Backup/Run Time (Half Load) : 26 Minute
  • Hot Swappable : Yes
  • Typical Battery Recharge Time : 8 Hour
  • Replaceable Battery : Yes
  • Maximum Operating Elevation : 10000 ft (3048000 mm)
  • Maximum Storage Elevation : 50000 ft (15240000 mm)
  • Storage Temperature : 5°F (-15°C) - 113°F (45°C)
  • Operating Humidity : 0% - 95%
  • Minimum Operating Temperature : 32°F (0°C)
  • Maximum Operating Temperature : 104°F (40°C)
  • Thermal Dissipation : 4332 BTU/h
  • Product Color : Black
  • Height : 8.74" (222 mm)
  • Width : 17.01" (432 mm)
  • Depth : 24.25" (616 mm)
  • Rack Height : 5U
  • Form Factor : Tower/Rack Convertible
  • Weight (Approximate) : 222.01 lb (100700 g)
  • Software Included : PowerPanel® Business Edition
  • Energy Star : Yes
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Limited Warranty : 3 Year
  • Additional Warranty Information :

    Three-year warranty (including coverage of batteries)

  • Capacity: 5000 VA / 4500 W
  • Topology: Line Interactive
  • Waveform: Sine Wave
  • Output: 208Vac ± 5%
  • Plug type & cord: NEMA L6-30P, 10 ft. cord
  • Outlets: 5 (2 critical load, 3 non-critical)
  • Outlet types: 3 x NEMA L6-30R, 2 x NEMA L6-20R
  • Communication: USB, Serial, SNMP, Relay, EPO
  • Data line protection: Telephone, Network
  • Management software: PowerPanel® Business Edition
  • Cisco compatible: Yes
  • Remote management: Yes
  • Environmental sensor: Yes, with optional RMCARD205
  • ENERGY STAR® qualified: Yes
  • Warranty: 3 year
  • Connected Equipment Guarantee: $300,000

SPECIFICATIONS

Manufacturer CyberPower Systems, Inc
Manufacturer Part Number PR5000LCDRTXL5U
Manufacturer Website Address https://www.cyberpowersystems.com/
Brand Name CyberPower
Product Line Smart App Sinewave
Product Model PR5000LCDRTXL5U
Product Name Smart App Sinewave PR5000LCDRTXL5U 5000VA Tower/rack convertible UPS
Product Type Line-interactive UPS
AVR Yes
Plug/Connector Type NEMA L6-30P
Receptacle Type NEMA L6-30R
Receptacle Type NEMA L6-20R
Receptacle Detail 2 x NEMA L6-20R
Receptacle Detail 3 x NEMA L6-30R
Number of Battery & Surge Outlets 5
Number of Critical Load Outlets 2
Dataline Protection Coax
Dataline Protection RJ-11/RJ-45
Overload Protection Yes
Emergency Power OFF Yes
Cord Length 10 ft (3.05 m)
Transfer Time 4 ms
EMI/RFI Noise Filter Yes
Energy Saving GreenPower UPS™ Bypass Technology
Application/Usage VoIP
Application/Usage Workstation
Application/Usage Mission Critical Equipment
Application/Usage Telecommunication
Application/Usage Network Device
Application/Usage Storage
Application/Usage Corporate
Application/Usage Server
Surge Suppression Yes
Features Cold Start Function
Features Audible Alarm
Features Auto Restart
Features Auto Charge
Features Self Test
Load Capacity (VA) 5 kVA
Load Capacity (Watt) 4.50 kW
Input Voltage 230 V AC
Input Voltage Range 148 V AC - 254 V AC
Input Voltage Range 208 V AC - 240 V AC
Input Voltage Range 131 V AC - 268 V AC
Output Voltage 208 V AC
Input Frequency 63 Hz
Input Frequency 47 Hz
Output Frequency 50 Hz
Output Frequency 60 Hz
Waveform Type Sine Wave
Surge Energy Rating 2430 J
Circuit Breaker Yes
Output Power Factor 0.9
Display LCD
Network Management SNMP/HTTP Remote Monitoring
Network Management Relay-MS Card
Alarm Low Battery
Alarm Battery Mode
Alarm Overload
Status Indicators

LCD Panel:

  • Load/Current Level
  • Runtime
  • Battery Level Temperature (F & C)
  • Battery In Use
  • Input Voltage
  • Output Voltage
  • Output Frequency
  • Overload
  • Wiring Fault
  • Battery Shutdown Voltage
  • Static Frequency Tolerance
  • Slew Rate
  • Silent Mode
  • Normal Mode

LED Indicators:

  • Power On
Serial Port Yes
Network (RJ-45) Yes
USB Yes
EPO Port Yes
USB (HID Compliant) Port Yes
Number of Batteries 16
Battery Characteristics Sealed
Battery Chemistry Lead Acid
Battery Size 12V
Battery Capacity 9000 mAh
Backup/Run Time (Full Load) 10 Minute
Backup/Run Time (Half Load) 26 Minute
Typical Battery Recharge Time 8 Hour
Hot Swappable Yes
Replaceable Battery Yes
Minimum Operating Temperature 32°F (0°C)
Maximum Operating Temperature 104°F (40°C)
Storage Temperature 5°F (-15°C) - 113°F (45°C)
Maximum Operating Elevation 10000 ft (3048000 mm)
Maximum Storage Elevation 50000 ft (15240000 mm)
Operating Humidity 0% - 95%
Thermal Dissipation 4332 BTU/h
Color Family Black
Product Color Black
Height 8.74" (222 mm)
Width 17.01" (432 mm)
Depth 24.25" (616 mm)
Rack Height 5U
Form Factor Tower/Rack Convertible
Weight (Approximate) 222.01 lb (100700 g)
Certifications & Standards
  • FCC Class A certified
  • UL 1778
  • CSA C22.2 No. 107.3-05
Software Included PowerPanel® Business Edition
Energy Star Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Limited Warranty 3 Year
Additional Warranty Information

Three-year warranty (including coverage of batteries)

Directly Connected Equipment Guarantee $300000 Lifetime
