Ergotron StyleView Multi Component Mount for Keyboard, Flat Panel Display, Mouse - 24" Screen Support - 32 lb (14514.96 g) Load Capacity - 75 x 75, 100 x 100 - VESA Mount Compatible - Aluminum, Plastic

45-260-026
Also known as SY4743682

Ergotron StyleView Multi Component Mount for Keyboard, Flat Panel Display, Mouse - 24" Screen Support - 32 lb (14514.96 g) Load Capacity - 75 x 75, 100 x 100 - VESA Mount Compatible - Aluminum, Plastic ombo Arm with Worksurface (pol ished aluminum)

New! Log in or create an account to see price and availability


MARKETING INFORMATION

Durable polished aluminum construction! Also features a work surface with pull-out keyboard tray, which facilitates caregiver work flow.

Holds a monitor, bar-code scanner, keyboard, wrist rest and mouse on the same arm, providing easy, single-motion height adjustment. Work sitting or standing with the arm's ergonomic 25" (64 cm) LCD height adjustment range. A unique cable management system conceals and organizes cords, making cleaning easy.

DETAILS

  • Device Supported : Keyboard,Flat Panel Display,Mouse
  • Maximum Load Capacity : 32 lb (14514.96 g)
  • Maximum Screen Size Supported : 24"
  • Features : Tilt,Swivel
  • Product Material : Aluminum,Plastic
  • VESA Mount Compatible : Yes
  • Mounting Pattern : 75 x 75,100 x 100
  • Compatibility : LCD Screen
  • Country of Origin : China
  • Limited Warranty : 5 Year
  • Sustains a maximum load capacity of 32 lb (14514.96 g)
  • Supports the screen size of 24"

SPECIFICATIONS

Manufacturer Ergotron, Inc
Manufacturer Part Number 45-260-026
Manufacturer Website Address http://www.ergotron.com
Brand Name Ergotron
Product Line StyleView
Product Name StyleView Sit-Stand Combo Arm with Worksurface
Product Type Multi Component Mount
Device Supported Keyboard
Device Supported Flat Panel Display
Device Supported Mouse
Maximum Load Capacity 32 lb (14514.96 g)
Maximum Screen Size Supported 24"
Features Tilt
Features Swivel
VESA Mount Compatible Yes
Mounting Pattern 100 x 100
Mounting Pattern 75 x 75
Product Material Plastic
Product Material Aluminum
Package Contents
  • Combo Arm
  • Wall Mount Bracket
  • Track Mount Bracket Kit
  • Height Adjustable LCD Mount
  • Wrist Rest
  • Scanner and Mouse Holder
  • Worksurface with Integrated Keyboard Tray
  • VESA Monitor Mounting Kit
  • Cable Tie
  • Mounting Hardware
Additional Information
  • Weight Capacity - Display = 6-18 lbs
  • Weight Capacity - Worksurface = 10 lbs
  • Weight Capacity - Keyboard, mouse and barcode scanner = 4 lbs
  • Easy-to-clean features promote superior infection control
  • Barcode scanner holder provides easy access to hand-held scanner
  • Extend LCD and keyboard up to 43" from wall
  • Clean, concealed and neat routing of cables through the expansive cable management system
  • LCD and keyboard adjusts 20" in tandem with single-motion
  • LCD adjusts 5" independently
  • Maximum LCD height adjustment = 25"
  • Monitor up/down tilt = +25°/-5°
Compatibility LCD Screen
Certifications & Standards

VESA:

  • FDMI
  • MIS-D
  • C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Country of Origin China
Limited Warranty 5 Year
