StarTech.com 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio - Control up to 4 high resolution multimedia computers from a single console - usb kvm switch - DVI KVM Switch - USB DVI KVM Switch -dvi dual link kvm
SV431DVIUAHR
Also known as SY4405633
MARKETING INFORMATION
The SV431DVIUAHR 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio provides simple, yet comprehensive KVM control of up to 4 directly connected computers with dual link DVI output and USB keyboard and mouse connections.
Audio switching capability and support for high resolution dual link DVI applications up to 2560x1600 @ 60Hz (up to 3840x2400 at lower refresh rates), make this KVM a superior switching solution that integrates perfectly into multimedia environments.
The DVI USB KVM Switch is compatible with all USB supported operating systems with no software or drivers to install, and features a built-in USB 2.0 hub that allows you to share up to 3 high speed USB devices between computers.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
Rackmount your KVM switch
If you'd like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket(sold separately) that turns this KVM into a rackmountable KVM.
More from the Manufacturer
DETAILS
- Number of Computers Supported : 4
- Number of Local Users Supported : 1
- Graphic Mode : WQXGA
- Maximum Video Resolution : 2560 x 1600
- USB : Yes
- DVI : Yes
- Number of USB Ports : 8
- Number of DVI Ports : 5
- Input Voltage Range : 100V AC to 240V AC
- Form Factor : Rack-mountable,Desktop
- Rack Height : 1U
- Height : 1.70" (43.18 mm)
- Width : 8.70" (220.98 mm)
- Depth : 5.10" (129.54 mm)
- Weight (Approximate) : 3.86 lb (1750 g)
- Package Contents :
- 4 Port USB DVI Dual Link KVM Switch with Audio
- 1 x Rubber Foot Pad
- 1 x Power Adapter
- 1 x User Manual
- Environmentally Friendly : Yes
- Country of Origin : Taiwan
- TAA Compliant : Yes
- Limited Warranty : 3 Year
- All metal chassis for long-term durability
- Supports dual link DVI resolutions up to 2560x1600 @ 60Hz
- Higher resolutions up to 3840x2400 supported at lower refresh rates
- Integrated USB 2.0 hub allows you to share up to 3 high-speed USB devices between computers
- Compatible with all USB supported Operating Systems
- Front panel push button computer selection
- HDCP Compliant
SPECIFICATIONS
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SV431DVIUAHR |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | 4 Port USB DVI Dual Link KVM Switch with Audio |
| Packaged Quantity | 1 Each |
| Product Type | KVM Switchbox |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| Daisy Chain Supported | Yes |
| Graphic Mode | WQXGA |
| Maximum Video Resolution | 2560 x 1600 |
| USB | Yes |
| DVI | Yes |
| Number of USB Ports | 8 |
| Number of DVI Ports | 5 |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Input Voltage Range | 100V AC to 240V AC |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Rack-mountable |
| Form Factor | Desktop |
| Rack Height | 1U |
| Height | 1.70" (43.18 mm) |
| Width | 8.70" (220.98 mm) |
| Depth | 5.10" (129.54 mm) |
| Weight (Approximate) | 3.86 lb (1750 g) |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Limited Warranty | 3 Year |
