MARKETING INFORMATION

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks

This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111G chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution

This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

The ST1000SPEX43 is backed by a StarTech.com 2-year hardware warranty and free lifetime technical support.

More from the Manufacturer

More from the Manufacturer

DETAILS

• Chipset Manufacturer : Realtek
• Chipset Model : RTL8111G
• Host Interface : PCI Express x4
• Total Number of Ports : 4
• Number of Network (RJ-45) Ports : 4
• Media Type Supported : Twisted Pair
• Maximum Data Transfer Rate : 1.95 Gbit/s
• Network Technology : 10/100/1000Base-T
• Color Family : Yellow
• Product Color : Yellow
• Form Factor : Plug-in Card
• Height : 0.70" (17.78 mm)
• Width : 4.70" (119.38 mm)
• Depth : 5.40" (137.16 mm)
• Weight (Approximate) : 3.40 oz (96.39 g)
• Device Supported : Computer,Server,Workstation
• Environmentally Friendly : Yes
• Environmental Compliance : Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS)
• Country of Origin : Taiwan
• TAA Compliant : Yes

• Add four independent Gigabit RJ45 ports to connect to multiple networks for high-bandwidth workstations and servers
• Realtek RTL8111G chipset for reliable performance
• Supports full-duplex flow control
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab networks
• Supports autonegotiation with next-page capacity
• Crossover detection and auto-correction (Auto-MDIX)
• Up to 9K jumbo frame support
• Support for IEEE 802.1Q VLAN tagging and IEEE 802.1P layer 2 priority encoding
• Microsoft NDIS5 checksum offload (IP, TCP, UDP) and large send offload support
