APC by Schneider Electric Smart-UPS SRT 2200VA RM 120V - 2U Rack-mountable - 3 Hour Recharge - 120 V Input - 120 V AC Output - Sine Wave - 1 x NEMA L5-20R, 6 x NEMA 5-20R Receptacle(s) - 7 x Battery/Surge Outlet - SmartSlot
SRT2200RMXLA
Also known as SRT2200RMXLACA,IM3313CW,SY5705934
MARKETING INFORMATION
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2200VA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 6x NEMA 5-20R and 1x NEMA L5-20R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty.DETAILS
- Plug/Connector Type : NEMA 5-20P
- Receptacle Type : NEMA 5-20P
- Receptacle Detail : 1 x NEMA L5-20R,6 x NEMA 5-20R
- Number of Battery & Surge Outlets : 7
- Cord Length : 6 ft (1.83 m)
- Application/Usage : Server,Network Workstation
- Load Capacity (VA) : 2.20 kVA
- Load Capacity (Watt) : 1.80 kW
- Input Voltage : 120 V
- Output Voltage : 120 V AC
- Input Frequency : 70 Hz
- Waveform Type : Sine Wave
- Surge Energy Rating : 340 J
- Network Management : SmartSlot
- Status Indicators : LCD Display
- EPO Port : Yes
- DC System Voltage : 72 V DC
- Number of Batteries : 1
- Battery Chemistry : Lead Acid
- Battery Energy : 1101.6 kJ
- Battery Life : 5 Year
- Hot Swappable : Yes
- Typical Battery Recharge Time : 3 Hour
- Replaceable Battery : Yes
- Maximum Operating Elevation : 10000 ft (3048000 mm)
- Maximum Storage Elevation : 50000 ft (15240000 mm)
- Storage Temperature : -4°F (-20°C) - 122°F (50°C)
- Storage Relative Humidity : 0% - 95%
- Maximum Operating Temperature : 104°F (40°C)
- Sound Emission (A-Weighted) : 55 dB(A)
- Thermal Dissipation : 535 BTU/h
- Product Color : Black
- Height : 3.35" (85 mm)
- Width : 17.01" (432 mm)
- Depth : 22.99" (584 mm)
- Rack Height : 2U
- Form Factor : Rack-mountable
- Weight (Approximate) : 55.01 lb (24952.12 g)
- Software Included : Powerchute Serial Edition
- Energy Star : Yes
- Country of Origin : Philippines
- Environmentally Friendly : Yes
- Energy Efficiency Certification : ENERGY STAR 2.0
- Environmental Compliance : Restriction of Hazardous Substances (RoHS)
- Limited Warranty : 3 Year
- Additional Warranty Information : 3 years repair or replace (excluding battery) and 2 years for battery
- 1.80 kW load capacity - backup power for your valuable electronics
- Prevent critical data loss by staying powered during a blackout with up to 1.80 kW load capacity
- 2.20 kVA load capacity - work without any interruption during power outages
- 2.20 kVA load capacity provides sufficient backup during power failures
SPECIFICATIONS
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SRT2200RMXLA |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS SRT 2200VA RM 120V |
| Product Type | Double Conversion Online UPS |
| Plug/Connector Type | NEMA 5-20P |
| Receptacle Type | NEMA 5-20P |
| Receptacle Detail | 1 x NEMA L5-20R |
| Receptacle Detail | 6 x NEMA 5-20R |
| Number of Battery & Surge Outlets | 7 |
| Cord Length | 6 ft (1.83 m) |
| Application/Usage | Server |
| Application/Usage | Network Workstation |
| Load Capacity (VA) | 2.20 kVA |
| Load Capacity (Watt) | 1.80 kW |
| Input Voltage | 120 V |
| Output Voltage | 120 V AC |
| Input Frequency | 70 Hz |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 340 J |
| Network Management | SmartSlot |
| Status Indicators | LCD Display |
| EPO Port | Yes |
| DC System Voltage | 72 V DC |
| Number of Batteries | 1 |
| Battery Chemistry | Lead Acid |
| Battery Energy | 1101.6 kJ |
| Battery Life | 5 Year |
| Typical Battery Recharge Time | 3 Hour |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Maximum Operating Temperature | 104°F (40°C) |
| Storage Temperature | -4°F (-20°C) - 122°F (50°C) |
| Maximum Operating Elevation | 10000 ft (3048000 mm) |
| Maximum Storage Elevation | 50000 ft (15240000 mm) |
| Storage Relative Humidity | 0% - 95% |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Thermal Dissipation | 535 BTU/h |
| Color Family | Black |
| Product Color | Black |
| Height | 3.35" (85 mm) |
| Width | 17.01" (432 mm) |
| Depth | 22.99" (584 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Mounting Preference | Lower |
| Mounting Location | Front |
| Weight (Approximate) | 55.01 lb (24952.12 g) |
| For Country/Region | United States |
| Package Contents | |
| Certifications & Standards | ENERGY STAR V2.0 (USA) |
| Software Included | Powerchute Serial Edition |
| Energy Star | Yes |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| Mercury Free | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SRT2200RMXLA_ROHS_DECLARATION&p_FileName=SRT2200RMXLAKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=458563181&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=458563181&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612036_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612036_EN |
| California Proposition 65 Warning | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Energy Star URL | https://www.energystar.gov/products/uninterruptible_power_supplies |
| REACH free of SVHC | No |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3 years repair or replace (excluding battery) and 2 years for battery |
