MARKETING INFORMATION

Optimized for surveillance onboard buses, this discreet, fisheye camera delivers outstanding images in any light conditions. It offers built-in cybersecurity features and support for advanced analytics based on deep learning on the edge.

360° view with just one camera

Designed to withstand strong shock and vibrations, this fisheye camera is optimized for surveillance onboard buses. And you don't need to invest in several cameras-with AXIS M4318-PLR you get a complete 180° or 360° overview for total situational awareness. Plus, there's just one camera to install, one cable to drop, one IP address, onevideo managementsoftware (VMS) license, and just one license for any analytics you choose to install. Furthermore, this cost-efficient camera ensures a lower power budget.

Outstanding images

With a stereographic lens and Sharpdome 360, AXIS M4318-PLR delivers greater sharpness at the edges of the image. It features a 12 MP sensor and offers great image quality around the clock, regardless of the light conditions.Forensic WDRprovides clarity when there's both dark and light areas in the scene. And Lightfinder for sharp, color images in low light. Thanks to built-in IR illumination with individually controllable LEDs, it delivers clear, reflection-free footage even in low light or complete darkness. Furthermore, it supports up to four digital PTZ views as well as dewarped panorama, quad, corner, and corridor views.

Secure and easy

AXIS M4318-PLR offers built-incybersecurityfeatures to help prevent unauthorized access and safeguard your system. For instance, AxisEdge Vaultprotects your Axis device ID and simplifies authorization of Axis devices on your network. AxisZipstreamwith H.264/H.265 significantly reduces bandwidth and storage requirements. Furthermore, with adeep learning processing unit (DLPU), this high-performance cameradelivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video.

DETAILS

• HD Recording : Yes
• Recording Formats : 4K
• Night Vision : Yes
• Night Vision Distance : 49.21 ft (15 m)
• Night Vision Type : Infrared
• Camera Iris : Fixed
• Image Sensor Type : CMOS
• Image Sensor Size : 1/2.3"
• Color Supported : Color
• Field of View : Horizontal field of view: 182° Vertical field of view: 182°
• Effective Camera Resolution : 12 Megapixel
• Video Formats : H.264M (MPEG-4 Part 10/AVC),H.264H (MPEG-4 Part 10/AVC),Motion JPEG,Zipstream,H.264M,H.264H,H.265
• Maximum Video Resolution : 3840 x 2160
• Maximum Frame Rate : 30 fps
• Lens Type : Fixed
• Maximum Focal Length : 1.2 mm (0.05")
• Lens Included : Yes
• Maximum Aperture : f/2.2
• Shortest Shutter Speed : 1/8100 Second
• Longest Shutter Speed : 1/2 Second
• Connectivity Technology : Wired
• Remote Management : Yes
• Ethernet Technology : Fast Ethernet
• Protocols : ONVIF,IPv4,MQTT,IPv6 USGv6,ICMPv4/ICMPv6,HTTP,HTTPS,TLS,DiffServ (QoS),FTP,SFTP,CIFS/SMB,SMTP,mDNS (Bonjour),UPnP,SNMPv1/v2c/v3 (MIB2),DNS/DNSv6,DDNS,NTP,NTS,RTSP,RTP,SRTP/RTSPS,TCP,UDP,IGMPv1/v2/v3,RTCP,ICMP,DHCPv4/v6,ARP,SSH,LLDP,SIP,CDP,MQTT v3.1.1,ZeroConf,IEEE 802.1X
• Storage Type : Memory Card
• Network (RJ-45) : Yes
• Maximum Power Consumption : 12.95 W
• Power Source Type : PoE
• Color Family : White
• Product Color : White
• Mount Type : Bracket Mount,Junction Box Mount
• Form Factor : Fisheye
• Height : 2.76" (70 mm)
• Diameter : 5.87" (149 mm)
• Weight (Approximate) : 1.90 lb (860 g)
• Minimum Operating Temperature : -40°F (-40°C)
• Maximum Operating Temperature : 122°F (50°C)
• Maximum Operating Humidity : 100%
• Features : Wide Dynamic Range,Day/Night,Video Management System,Motion Detection,Multi-view Stream,Audio Compression,HTTPS Encryption,Privacy Masking,Mirror,White Balance
• Indoor/Outdoor : Outdoor
• Impact Protection Rating : IK10
• Ingress Protection Rating : IP66
• TAA Compliant : Yes

• For remote surveillance needs, this network camera is best suited
• Up to 3840 x 2160 resolution for surveillance in real-time
• CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
• Provides night vision of objects at a distance of up to 49.21 ft (15 m)
