Cisco Catalyst 8500 Ethernet Switch - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-X, 10GBase-X - Refurbished - 2 Layer Supported - Optical Fiber - Gray - 1U - Rack-mountable
C8500L-8S4X-RF
Also known as IMBT8555
DETAILS
- Port/Expansion Slot Details : 4 x 10 Gigabit Ethernet SFP+ Expansion Slot,8 x Gigabit Ethernet SFP Expansion Slot
- Media Type Supported : Optical Fiber
- Ethernet Technology : Gigabit Ethernet,10 Gigabit Ethernet
- Network Technology : 1000Base-X,10GBase-X
- Total Number of Expansion Slots : 12
- Expansion Slot Type : SFP+
- Number of SFP+ Slots : 12
- Layer Supported : 2
- Networking Standards : IEEE 802.1ag,IEEE 802.3ah,IEEE 802.1Q
- Manageable : Yes
- Input Voltage : 120 V AC,230 V AC,-40 V DC,-60 V DC
- Power Source : AC/DC
- Product Color : Gray
- Compatible Rack Unit : 1U
- Form Factor : Rack-mountable
- Height : 1.73" (43.94 mm)
- Width : 17.50" (444.50 mm)
- Depth : 16.25" (412.75 mm)
- Weight (Approximate) : 17 lb (7711.07 g)
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- Rack mounting enables you to organize wires & secure cables for professional installation
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
SPECIFICATIONS
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | C8500L-8S4X-RF |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Line | Catalyst |
| Product Series | 8500 |
| Product Name | Catalyst 8500 Ethernet Switch |
| Product Condition | Refurbished |
| Product Type | Ethernet Switch |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet SFP Expansion Slot |
| Port/Expansion Slot Details | 4 x 10 Gigabit Ethernet SFP+ Expansion Slot |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 1000Base-X |
| Network Technology | 10GBase-X |
| Total Number of Expansion Slots | 12 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 12 |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3ah |
| Networking Standards | IEEE 802.1ag |
| Networking Standards | IEEE 802.1Q |
| Manageable | Yes |
| Input Voltage | -60 V DC |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Input Voltage | -40 V DC |
| Power Source | AC/DC |
| Color Family | Gray |
| Product Color | Gray |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 16.25" (412.75 mm) |
| Weight (Approximate) | 17 lb (7711.07 g) |
| Application/Usage | Network |
| Application/Usage | Office |
| Application/Usage | Enterprise |
| Application/Usage | Business |
