APC Smart-UPS 1000VA - 1000VA/640W - 5.4 Minute Full Load - 4 x IEC 320-C13, 2
SUA1000RMI1U
Also known as IM94371U
MARKETING INFORMATION
Smart-UPS protects your data by supplying network-grade battery backup when power fails. With PowerChute® plus software the uninterruptible power supply (UPS) will safely store data and shut down your network operating system before the battery is fully discharged, whether you're there or not. SmartSlot internal accessory slot allows you to install optional accessories to enhance the performance of your UPS. APC Smart-UPS is the perfect UPS for fileservers, minicomputers, UNIX CPU's, internet hubs, telecommunications systems and other mission-critical applications.DETAILS
- Plug/Connector Type : IEC 320-C14
- Receptacle Type : IEC 60320 C13
- Receptacle Detail : 4 x IEC 60320 C13,2
- Number of Battery & Surge Outlets : 6
- Load Capacity (VA) : 1 kVA
- Load Capacity (Watt) : 640 W
- Input Voltage : 220 V AC
- Output Voltage : 230 V AC
- Waveform Type : Sine Wave
- Surge Energy Rating : 480 J
- Network Management : SNMP Manageable
- Alarm : Low Battery,On Battery
- Status Indicators :
- On Battery
- Replace Battery
- Overload
- Serial Port : Yes
- USB : Yes
- Battery Characteristics : Spill-proof, Maintenance-free
- Battery Chemistry : Lead Acid
- Backup/Run Time (Full Load) : 5.40 Minute
- Backup/Run Time (Half Load) : 14.50 Minute
- Hot Swappable : Yes
- Maximum Operating Temperature : 113°F (45°C)
- Thermal Dissipation : 130 BTU/h
- Product Color : Black
- Height : 1.72" (43.69 mm)
- Width : 17" (431.80 mm)
- Depth : 26" (660.40 mm)
- Rack Height : 1U
- Form Factor : Rack-mountable
- Weight (Approximate) : 48 lb (21772.43 g)
- Package Contents :
- Smart-UPS 1000VA
- CD with software
- Rack mounting brackets
- Rack mounting support rails
- Smart UPS signalling RS-232 cable
- USB cable
- User manual
- Environmentally Friendly : Yes
- Limited Warranty : 2 Year
- Works adequately in situations where the supply is prone to sags and surges
- 640 W load capacity - backup power for your valuable electronics
- Up to 5.40 minute runtime on full load to preserve critical data from power shortage interruptions
- 1 kVA load capacity - work without any interruption during power outages
SPECIFICATIONS
Manufacturer | Schneider Electric SA |
Manufacturer Part Number | SUA1000RMI1U |
Manufacturer Website Address | http://www.schneider-electric.com |
Brand Name | APC by Schneider Electric |
Product Line | Smart-UPS |
Product Series | SUA |
Product Name | Smart-UPS 1000VA |
Packaged Quantity | 1 Each |
Product Type | Line-interactive UPS |
Plug/Connector Type | IEC 320-C14 |
Receptacle Type | IEC 60320 C13 |
Receptacle Detail | 2 |
Receptacle Detail | 4 x IEC 60320 C13 |
Number of Battery & Surge Outlets | 6 |
Load Capacity (VA) | 1 kVA |
Load Capacity (Watt) | 640 W |
Input Voltage | 220 V AC |
Output Voltage | 230 V AC |
Waveform Type | Sine Wave |
Surge Energy Rating | 480 J |
Network Management | SNMP Manageable |
Alarm | Low Battery |
Alarm | On Battery |
Battery Management | Intelligent Battery Management |
Status Indicators |
|
Serial Port | Yes |
USB | Yes |
Total Number of Expansion Slots | 1 |
Battery Characteristics | Spill-proof, Maintenance-free |
Battery Chemistry | Lead Acid |
Backup/Run Time (Full Load) | 5.40 Minute |
Backup/Run Time (Half Load) | 14.50 Minute |
Hot Swappable | Yes |
Maximum Operating Temperature | 113°F (45°C) |
Thermal Dissipation | 130 BTU/h |
Color Family | Black |
Product Color | Black |
Height | 1.72" (43.69 mm) |
Width | 17" (431.80 mm) |
Depth | 26" (660.40 mm) |
Rack Height | 1U |
Form Factor | Rack-mountable |
Weight (Approximate) | 48 lb (21772.43 g) |
Package Contents | |
Additional Information |
|
Certifications & Standards |
|
Environmentally Friendly | Yes |
Limited Warranty | 2 Year |
