This robust, high-performance PTZ camera offers UHD 4K with 20x optical zoom for outstanding video quality. It's ideal for demanding situations in wide, outdoor areas such as cities, airports, and critical infrastructure applications.

Great overviews and superior detail

Based on a powerful Axis chipset, AXIS Q6078-E offers UHD 4K resolution and 20x optical zoom for outstanding video quality. Ideal for wide-area coverage, it delivers great overviews, and you can zoom in for detailed views with the clearest, sharpest colors. Featuring Axis Zipstream technology with support for H.264 and H.265 it preserves all the important forensic details while significantly reducing bandwidth and storage requirements.

Whenever, wherever it's needed

This outdoor, vandal-resistant camera is IP66, NEMA 4X, and IK10-rated to protect against dust, rain, snow, and impacts. Arctic temperature control ensures startup from a deeply frozen state and operation in temperatures ranging from -40 °C to 50 °C (-40 °F to 122 °F). Autotracking 2 with click and track functionality and an orientation aid allows for active object tracking and quick orientation. Additionally, where privacy must be kept, privacy masking with mosaic lets you pixelate whole areas such as a neighboring property. Furthermore, AXIS Q6078-E features AXIS Object Analytics allowing you to detect and classify humans and vehicles, all tailored to your specific needs.

Designed with cybersecurity in mind

AXIS Q6078-E is packed with built-in cybersecurity features to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantee that the firmware hasn't been compromised and ensures only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware after a factory default. For added peace of mind, it includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified. This module ensures secure storage of all cryptographic keys and certificates even in the event of a security breach.

DETAILS

• HD Recording : Yes
• Recording Formats : 4K
• Image Sensor Type : RGB CMOS
• Color Supported : Color
• Field of View : 68.3°-4.2° - 42.1°-2.34°
• Effective Camera Resolution : 8 Megapixel
• Video Formats : H.264 (MPEG-4 Part 10/AVC),H.265 (MPEG-H Part 2/HEVC),Motion JPEG,H.264,H.265,H.264 BP,H.264 (MP),H.264 HP,H.265 (MP),Zipstream,H.264B,H.264H,H.264M
• Maximum Video Resolution : 3840 x 2160
• Maximum Frame Rate : 60 fps
• Lens Type : Varifocal
• Minimum Focal Length : 4.4 mm (0.17")
• Maximum Focal Length : 88.4 mm (3.48")
• Lens Included : Yes
• Minimum Aperture : f/3.8
• Maximum Aperture : f/2
• Optical Zoom : 20x
• Shortest Shutter Speed : 1/10000 Second
• Longest Shutter Speed : 1 Second
• Connectivity Technology : Wired
• Remote Management : Yes
• Storage Type : Memory Card
• Network (RJ-45) : Yes
• Input Voltage : 240 V AC
• Power Source Type : PoE
• Color Family : White
• Product Color : White
• Mount Type : Corner Mount,Bracket Mount,Ceiling Mount,Pole Mount,Parapet Mount,Wall Mount,Pendant Mount,Recessed Mount
• Form Factor : Dome
• Durability : Vandal Resistant,Dust Resistant,Rain Resistant,Snow Resistant,Impact Resistant
• Height : 10.60" (269.24 mm)
• Width : 9.13" (232 mm)
• Diameter : 9.13" (232 mm)
• Weight (Approximate) : 8.27 lb (3750 g)
• Minimum Operating Temperature : -58°F (-50°C)
• Maximum Operating Temperature : 122°F (50°C)
• Maximum Operating Humidity : 100%
• Features : PTZ,Day/Night,Wide Dynamic Range,White Balance,Privacy Masking,Electronic Image Stabilization,Defog,Back Light Compensation (BLC),Password Protection,HTTPS Encryption,Cross Line Detection,Motion Detection
• Indoor/Outdoor : Outdoor
• Impact Protection Rating : IK10
• Ingress Protection Rating : IP66,IP67
• Country of Origin : Mexico
• TAA Compliant : Yes
• Limited Warranty : 5 Year

• For remote surveillance needs, this network camera is best suited
• Up to 3840 x 2160 resolution for surveillance in real-time
• Features RGB CMOS sensor
