TP-Link 16-Port Gigabit Easy Smart Switch - 16 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - 10.22 W Power Consumption - Twisted Pair - 1U - Desktop, Rack-mountable
TL-SG1016DE
Also known as IM87278Y,DHTLSG1016DECA
MARKETING INFORMATION
What This Product DoesThe TL-SG1016DE 16-Port Gigabit Easy Smart switch is an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG1016DE offers both port and tag based QoS to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG1016DE can save up to 40% of power consumption, making it an eco-friendly solution for your business network.
DETAILS
- Total Number of Network Ports : 16
- Network (RJ-45) : Yes
- Modular : No
- Stack Port : No
- Port/Expansion Slot Details : 16 x Gigabit Ethernet Network
- Media Type Supported : Twisted Pair
- Ethernet Technology : Gigabit Ethernet
- Network Technology : 10/100/1000Base-T
- Layer Supported : 2
- Networking Standards : IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1p
- Manageable : Yes
- PoE (RJ-45) Port : No
- Power Source : Power Supply
- Power Consumption : 10.22 W
- Compatible Rack Unit : 1U
- Form Factor : Desktop,Rack-mountable
- Height : 1.70" (43.18 mm)
- Width : 11.60" (294.64 mm)
- Depth : 7.10" (180.34 mm)
- Package Contents :
- 16-Port Gigabit Easy Smart Switch
- Power Cord
- Installation Guide
- Resource CD
- Rackmount Kit
- Rubber Feet
- Country of Origin : China
- 16-Gigabit ports provide instant large file transfers.
- 9K Jumbo frame improves performance of large data transfers.
- Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics.
- Abundant VLAN features improve network security via traffic segmentation.
- IGMP Snooping optimizes multicast applications.
- Port and tag-based QoS enable smooth latency-sensitive traffic.
- LIMITED LIFETIME WARRANTY and 24/7 Tech Support.
SPECIFICATIONS
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | TL-SG1016DE |
| Manufacturer Website Address | http://www.tp-link.com |
| Brand Name | TP-Link |
| Product Model | TL-SG1016DE |
| Product Name | 16-Port Gigabit Easy Smart Switch |
| Product Type | Ethernet Switch |
| Total Number of Network Ports | 16 |
| Token Ring Port | No |
| LRE Port | No |
| Bypass | No |
| Modular | No |
| Stack Port | No |
| Number of Network (RJ-45) Ports | 16 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 16 x Gigabit Ethernet Network |
| Media Type Supported | Twisted Pair |
| Twisted Pair Cable Standard | Category 6 |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1Q |
| Networking Standards | IEEE 802.1p |
| Networking Standards | IEEE 802.3x |
| Networking Standards | IEEE 802.3ab |
| Networking Standards | IEEE 802.3u |
| Networking Standards | IEEE 802.3i |
| Manageable | Yes |
| Management |
|
| PoE (RJ-45) Port | No |
| Power Source | Power Supply |
| Power Consumption | 10.22 W |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Form Factor | Desktop |
| Height | 1.70" (43.18 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 7.10" (180.34 mm) |
| Package Contents |
|
| Country of Origin | China |
