MARKETING INFORMATION

Delivering performance, versatility and density without compromise, the Cisco UCS B200 M5 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.

The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco's Unified Computing System portfolio in a half-width blade form factor.

DETAILS

• Number of Processors Supported : 2
• Processor Supported : Xeon
• 64-bit Processing : Yes
• Chipset Manufacturer : Intel
• Chipset Model : C621
• Maximum Memory Supported : 3 TB
• Memory Technology : DDR4 SDRAM
• Memory Standard : DDR4-2933/PC4-23466
• Total Number of Memory Slots : 24
• Intel Optane Memory Ready : Yes
• Optical Drive Type : No
• Controller Type : 12Gb/s SAS
• RAID Supported : Yes
• Graphics Controller Model : G200e
• Graphics Memory Capacity : 8 MB
• Ethernet Technology : Ethernet
• Number of Total Expansion Bays : 2
• Total Number of USB Ports : 1
• Number of USB 3.0 Ports : 1
• Operating System Supported : Linux,Windows
• Form Factor : Blade
• Height : 1.95" (49.53 mm)
• Width : 8" (203.20 mm)
• Depth : 24.40" (619.76 mm)
• Weight (Approximate) : 9.50 lb (4310 g)

• Experience high performance, built-in security and remote management capabilities with Intel Xeon processor
• DDR4 SDRAM compatible slot - Allows the memory to operate at an effective bus speed while using minimal power, resulting in an optimal computer performance and improved memory heat dissipation
• Speed up workflows and increase productivity by sharing the organizational resources via Ethernet connectivity
• With 1 USB ports, connect/disconnect devices while not having to shut down the system
• 12Gb/s SAS interface for high speed and reliability
