APC by Schneider Electric Smart-UPS 750VA Rack-mountable UPS - 2U Rack-mountable - 3 Hour Recharge - 5 Minute Stand-by - 230 V Input - 230 V AC Output - Sine Wave - Serial Port - USB - 2 x IEC Jumper, 4 x IEC 320-C13 Receptacle(s) - 6 x Battery/Surge Outlet
SMT750RMI2U
Also known as IM72081U
MARKETING INFORMATION
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C14 input, 4 IEC 320 C13 outlets, and 2 IEC jumper cables. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.DETAILS
- Receptacle Type : IEC 320-C14
- Receptacle Detail : 2 x IEC Jumper,4 x IEC 320-C13
- Number of Battery & Surge Outlets : 6
- Load Capacity (VA) : 750 VA
- Load Capacity (Watt) : 500 W
- Input Voltage : 230 V
- Output Voltage : 230 V AC
- Waveform Type : Sine Wave
- Surge Energy Rating : 459 J
- Serial Port : Yes
- USB : Yes
- Network (RJ-45) : Yes
- Battery Characteristics : Spill-proof, Maintenance-free
- Battery Chemistry : Lead Acid
- Backup/Run Time (Full Load) : 5 Minute
- Backup/Run Time (Half Load) : 16 Minute
- Hot Swappable : Yes
- Typical Battery Recharge Time : 3 Hour
- Product Color : Black
- Height : 3.50" (89 mm)
- Width : 17.01" (432 mm)
- Depth : 15.98" (406 mm)
- Rack Height : 2U
- Form Factor : Rack-mountable
- Weight (Approximate) : 38.07 lb (17268.26 g)
- Software Included : Powerchute Serial Edition
- Country of Origin : Philippines
- Environmentally Friendly : Yes
- Environmental Compliance : Restriction of Hazardous Substances (RoHS)
- Limited Warranty : 3 Year
- Additional Warranty Information : 3 years repair or replace (excluding battery) and 2 years for battery
- Experience higher efficiency with lower energy cost
- Prevent critical data loss by staying powered during a blackout with up to 500 W load capacity
- Up to 5 minute runtime on full load to preserve critical data from power shortage interruptions
- 750 VA load capacity - work without any interruption during power outages
SPECIFICATIONS
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMT750RMI2U |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Model | SMT750RMI2U |
| Product Name | Smart-UPS 750VA Rack-mountable UPS |
| Product Type | Line-interactive UPS |
| Receptacle Type | IEC 320-C14 |
| Receptacle Detail | 4 x IEC 320-C13 |
| Receptacle Detail | 2 x IEC Jumper |
| Number of Battery & Surge Outlets | 6 |
| Load Capacity (VA) | 750 VA |
| Load Capacity (Watt) | 500 W |
| Input Voltage | 230 V |
| Output Voltage | 230 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 459 J |
| Serial Port | Yes |
| Network (RJ-45) | Yes |
| USB | Yes |
| Total Number of Expansion Slots | 1 |
| Battery Characteristics | Spill-proof, Maintenance-free |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 5 Minute |
| Backup/Run Time (Half Load) | 16 Minute |
| Typical Battery Recharge Time | 3 Hour |
| Hot Swappable | Yes |
| Color Family | Black |
| Product Color | Black |
| Height | 3.50" (89 mm) |
| Width | 17.01" (432 mm) |
| Depth | 15.98" (406 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Mounting Preference | Lower |
| Mounting Location | Front |
| Weight (Approximate) | 38.07 lb (17268.26 g) |
| Package Contents | |
| Certifications & Standards | CE|CSA|EAC|RCM|TÜV|VDE |
| Software Included | Powerchute Serial Edition |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| Mercury Free | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT750RMI2U_ROHS_DECLARATION&p_FileName=SMT750RMI2UKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=65035394&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=65035394&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612028_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612028_EN |
| REACH free of SVHC | No |
| WEEE Statement | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3 years repair or replace (excluding battery) and 2 years for battery |
