StarTech.com 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km - Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode ST fiber - fiber converter - ethernet media converter - fibre converter - 10/100 media converter - utp to fiber
MCM110ST2
Also known as IM69873L,SY4486387
MARKETING INFORMATION
The MCM110ST2 10/100 Multi Mode ST Fiber Ethernet Media Converter (2 km) creates a cost-effective Ethernet to fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over a multimode fiber backbone.The ST media converter supports a maximum multimode fiber optic cable distance of 2km (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using ST-terminated multimode fiber, while delivering solid network performance and scalability.
Easy to setup and install, this compact, value-conscious fast Ethernet media converter features auto-switching MDI and MDI-X support on the RJ45 UTP connections as well as manual controls for UTP mode, speed, Full and Half Duplex, as well as LFP (Link Fault pass-through) on/off.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
DETAILS
- Total Number of Ports : 2
- Network (RJ-45) : Yes
- Number of Network (RJ-45) Ports : 1
- Number of ST Ports : 1
- ST Port Type : Duplex
- Media Type Supported : Optical Fiber,Twisted Pair
- Fiber Mode Supported : Multi-mode
- Fiber Optic Cable Wavelength : 1310 nm
- Maximum Distance Supported : 2 km (1.24 Mile)
- Ethernet Technology : Fast Ethernet
- Network Technology : 10Base-T,100Base-FX
- Power Source : AC Adapter
- Power Consumption : 2.40 W
- Plug/Connector Type : Type M
- Form Factor : External
- Height : 0.80" (20.32 mm)
- Width : 3" (76.20 mm)
- Depth : 3.70" (93.98 mm)
- Weight (Approximate) : 2.90 oz (82.21 g)
- Package Contents :
- 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km
- 1 x Power Adapter
- 1 x Instruction Manual
- Environmentally Friendly : Yes
- Country of Origin : Taiwan
- TAA Compliant : Yes
- Limited Warranty : 2 Year
- Supports a maximum multi mode fiber optic cable distance of 2 km
- Supports full or half-duplex operation
- Compatible with 3com, Cisco, Lucent and Nortel networks
- Supports Link Fault Pass through (LFP)
- Supports IEEE 802.3 10Base-T, 802.3u 100Base-TX and 100Base-FX industry standards
- Supports IEEE 802.1q Tag VLAN pass thru
- Supports Q in Q double tagged frame transparent
- LED Indicators for simple Ethernet/Fiber network link monitoring
- Support flow control (Pause)
SPECIFICATIONS
| Manufacturer | StarTech.com |
| Manufacturer Part Number | MCM110ST2 |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km |
| Packaged Quantity | 1 Each |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of ST Ports | 1 |
| ST Port Type | Duplex |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Maximum Distance Supported | 2 km (1.24 Mile) |
| Ethernet Technology | Fast Ethernet |
| Network Technology | 100Base-FX |
| Network Technology | 10Base-T |
| Power Source | AC Adapter |
| Power Consumption | 2.40 W |
| Plug/Connector Type | Type M |
| Form Factor | External |
| Height | 0.80" (20.32 mm) |
| Width | 3" (76.20 mm) |
| Depth | 3.70" (93.98 mm) |
| Weight (Approximate) | 2.90 oz (82.21 g) |
| Package Contents |
|
| Additional Information |
|
| Environmentally Friendly | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Limited Warranty | 2 Year |
