APC by Schneider Electric Smart-UPS 2200VA LCD RM 2U 120V US - 2U Rack-mountable - 3 Hour Recharge - 5 Minute Stand-by - 120 V Input - 120 V AC Output - Sine Wave - USB - 2 x NEMA 5-20R, 6 x NEMA 5-15R Receptacle(s) - 8 x Battery/Surge Outlet

SMT2200RMUS
Also known as IM68004T

New! Log in or create an account to see price and availability


MARKETING INFORMATION

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1920VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 6 NEMA 5-15R and 2 NEMA 5-20R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.

More from the Manufacturer

DETAILS

  • Plug/Connector Type : NEMA 5-20P
  • Receptacle Type : NEMA 5-20P
  • Receptacle Detail : 2 x NEMA 5-20R,6 x NEMA 5-15R
  • Number of Battery & Surge Outlets : 8
  • Cord Length : 8 ft (2.44 m)
  • Load Capacity (VA) : 1.92 kVA
  • Load Capacity (Watt) : 1.98 kW
  • Input Voltage : 120 V
  • Output Voltage : 120 V AC
  • Waveform Type : Sine Wave
  • Surge Energy Rating : 530 J
  • USB : Yes
  • Battery Characteristics : Spill-proof, Maintenance-free
  • Battery Chemistry : Lead Acid
  • Backup/Run Time (Full Load) : 5 Minute
  • Backup/Run Time (Half Load) : 16 Minute
  • Hot Swappable : Yes
  • Typical Battery Recharge Time : 3 Hour
  • Product Color : Black
  • Height : 3.39" (86 mm)
  • Width : 18.90" (480 mm)
  • Depth : 26.89" (683 mm)
  • Rack Height : 2U
  • Form Factor : Rack-mountable
  • Weight (Approximate) : 93.28 lb (42311.10 g)
  • Software Included : Powerchute Serial Edition
  • Energy Star : Yes
  • Country of Origin : United States
  • TAA Compliant : Yes
  • Environmentally Friendly : Yes
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Limited Warranty : 3 Year
  • Additional Warranty Information : 3 years repair or replace (excluding battery) and 2 years for battery
  • 1.98 kW load capacity - backup power for your valuable electronics
  • Keep your sensitive devices powered with a backup of up to 5 minute at full load
  • Prevent critical data loss by staying powered during a blackout with up to 1.98 kW load capacity
  • Up to 5 minute runtime on full load to preserve critical data from power shortage interruptions
  • 1.92 kVA load capacity - work without any interruption during power outages
  • 1.92 kVA load capacity provides sufficient backup during power failures

SPECIFICATIONS

Manufacturer Schneider Electric SA
Manufacturer Part Number SMT2200RMUS
Manufacturer Website Address http://www.schneider-electric.com
Brand Name APC by Schneider Electric
Product Line Smart-UPS
Product Name Smart-UPS 2200VA LCD RM 2U 120V US
Product Type Line-interactive UPS
Plug/Connector Type NEMA 5-20P
Receptacle Type NEMA 5-20P
Receptacle Detail 2 x NEMA 5-20R
Receptacle Detail 6 x NEMA 5-15R
Number of Battery & Surge Outlets 8
Emergency Power OFF Yes
Cord Length 8 ft (2.44 m)
Load Capacity (VA) 1.92 kVA
Load Capacity (Watt) 1.98 kW
Input Voltage 120 V
Output Voltage 120 V AC
Waveform Type Sine Wave
Surge Energy Rating 530 J
USB Yes
Total Number of Expansion Slots 1
Battery Characteristics Spill-proof, Maintenance-free
Battery Chemistry Lead Acid
Backup/Run Time (Full Load) 5 Minute
Backup/Run Time (Half Load) 16 Minute
Typical Battery Recharge Time 3 Hour
Hot Swappable Yes
Color Family Black
Product Color Black
Height 3.39" (86 mm)
Width 18.90" (480 mm)
Depth 26.89" (683 mm)
Rack Height 2U
Form Factor Rack-mountable
Mounting Preference Lower
Mounting Location Front
Weight (Approximate) 93.28 lb (42311.10 g)
For Country/Region United States
Package Contents
  • Smart-UPS 2200VA LCD RM 2U 120V US
  • CD with software
  • Documentation CD
  • Rack mounting brackets
  • Rack mounting support rails
  • Smart UPS signalling RS-232 cable
  • USB cable
  • Certifications & Standards CSA|TAA compliance
    Software Included Powerchute Serial Edition
    Energy Star Yes
    Optimized Energy Efficiency Yes
    Product Take Back Program Yes
    Mercury Free Yes
    RoHS Exemption Information https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT2200RMUS_ROHS_DECLARATION&p_FileName=SMT2200RMUSKIT_ROHS_DECLARATION_US.pdf
    REACH Declaration URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=384166925&lang=en-us
    EU RoHS Declaration URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=384166925&lang=en-us
    Environmental Profile Availability https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN
    End of Life Manual Availability https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN
    California Proposition 65 Warning WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    REACH free of SVHC No
    Country of Origin United States
    TAA Compliant Yes
    Environmentally Friendly Yes
    Environmental Compliance Restriction of Hazardous Substances (RoHS)
    Limited Warranty 3 Year
    Additional Warranty Information 3 years repair or replace (excluding battery) and 2 years for battery
    Directly Connected Equipment Guarantee $150000 Lifetime
