Cisco Barebone System - 4U Rack-mountable - 2 x Processor Support - DDR4 SDRAM DDR4-2666/PC4-21300 Maximum RAM Support - 14 Total Memory Slots - 12Gb/s SAS RAID Supported Controller - 56 3.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - 40 Gigabit Ethernet, Gigab
UCS-S3260-M5SRB
Also known as IM662BBK
MARKETING INFORMATION
The Cisco UCS S3260 Storage Server is a modular, storage server with dual M4 or M5 server nodes, optimized for large datasets used in environments such as big data, cloud, object storage, video surveillance, and content delivery.DETAILS
- Number of Nodes : 2
- Number of Processors Supported : 2
- Processor Supported : Xeon Platinum,Xeon Gold,Xeon Silver,Xeon Bronze
- 64-bit Processing : Yes
- Memory Technology : DDR4 SDRAM
- Memory Standard : DDR4-2666/PC4-21300
- Total Number of Memory Slots : 14
- Controller Type : 12Gb/s SAS
- RAID Supported : Yes
- Ethernet Technology : 40 Gigabit Ethernet,Gigabit Ethernet
- Number of 3.5" Bays : 56
- Total Number of Expansion Slots : 2
- Number of PCI Express x8 Slots : 2
- Total Number of USB Ports : 2
- Input Voltage : 120 V AC,230 V AC
- Form Factor : Rack-mountable
- Rack Height : 4U
- Height : 6.88" (174.75 mm)
- Width : 17.46" (443.48 mm)
- Depth : 32" (812.80 mm)
- Weight (Approximate) : 195 lb (88450.51 g)
- Limited Warranty : 3 Year
- Perform computational tasks effectively accrediting the Xeon Platinum processor
- DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Can connect up to 2 USB peripherals
- 12Gb/s SAS interface for high speed and reliability
SPECIFICATIONS
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | UCS-S3260-M5SRB |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Series | S3260 M5 |
| Product Name | UCS S3260 M5 Barebone System |
| Product Type | Barebone System |
| Number of Nodes | 2 |
| Number of Processors Supported | 2 |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Silver |
| Processor Supported | Xeon Bronze |
| 64-bit Processing | Yes |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2666/PC4-21300 |
| Total Number of Memory Slots | 14 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 40 Gigabit Ethernet |
| Number of 3.5" Bays | 56 |
| Total Number of Expansion Slots | 2 |
| Number of PCI Express x8 Slots | 2 |
| Total Number of USB Ports | 2 |
| Input Voltage | 120 V AC |
| Input Voltage | 230 V AC |
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| Height | 6.88" (174.75 mm) |
| Width | 17.46" (443.48 mm) |
| Depth | 32" (812.80 mm) |
| Weight (Approximate) | 195 lb (88450.51 g) |
| Limited Warranty | 3 Year |
