MARKETING INFORMATION

The Seagate® Nytro® 5050 series NVMe solid state drive represents the next generation of enterprise SSDs. Engineered for efficiency, high performance, and increased storage density in data centers, Nytro 5050 SSD eliminates performance bottlenecks and significantly improves quality of service (QoS).

Best-in-class performance -PCIe Gen4 NVMe SSD doubles the random throughput of the latest SAS SSDs, achieving over ten times the bandwidth of SATA.

Blistering 7.4GB/s bandwidth and up to 1.7M IOPS removes data bottlenecks and provides consistent response times.

Boosted capacity in ultra-dense environments -up to 15TB supporting U.2 and U.3 interface, and dual ports support active active high availability.

Highly optimized, the Nytro 5350 withstands read-intensive workloads while the Nytro 5550 is built to endure mixed workloads.

Quintupled performance over SATA SSDs with 10x more bandwidth and IOPS over previous generations to get more computing using minimal space, energy, and cost.

Low latency and high quality of service deliver improved responsiveness and enhanced user experience.

Effortless serviceability and maintenance with no downtime requirements, and hot-swap capability for easy SSD addition, removal, or replacement.

Hardware-based encryption Self-Encrypting Drive (SED) models support the TCG standard to help keep valuable data secure.

Operating system friendly to easily integrate with Linux and Microsoft.

Enhanced durability and reliability with 1 and 3 DWPD at 2.5M MTBF-move massive enterprise data for the long haul.

DETAILS

• Storage Capacity : 12.80 TB
• Platform Supported : Linux,PC
• Maximum Read Transfer Rate : 7400 MB/s
• Maximum Write Transfer Rate : 7200 MB/s
• Random 4KB Read : 1700000IOPS
• Random 4KB Write : 495000IOPS
• Endurance (DWPD) : 3
• Endurance (TBW) : 70000 TB
• Endurance Type : Mixed Use
• Wireless LAN : No
• Drive Interface : PCI Express NVMe
• Drive Interface Standard : PCI Express NVMe 4.0 x4
• Drive Type : Internal
• Form Factor : 2.5"
• Hot Swappable : Yes
• Height : 0.59" (14.90 mm)
• Width : 2.76" (70.10 mm)
• Depth : 3.95" (100.40 mm)
• Weight (Approximate) : 6 oz (170 g)
• Device Supported : Server,Storage System
• Operating System Compatibility : Linux,Windows
• Limited Warranty : 5 Year

• With 12.80 TB capacity you have ample space for storing millions of images, hundreds of hours of video or for music lovers, up to a million songs
• The high-read speed of 7400 MB/s maximizes system performance and saves time while you are doing complex tasks
• With the high-write speed of 7200 MB/s, get a quick response when updating or transferring files
• PCI Express NVMe 4.0 x4 interface provides quick data transfer and greater throughput

SPECIFICATIONS
