StarTech.com 4-port PCI Express LP USB Adapter Card - Add 4 USB 2.0 ports to your low profile/small form factor computer through a PCI Express expansion slot - pci express usb 2.0 card - pci-e usb 2.0 card - pcie usb 2.0 card

PEXUSB4DP
Also known as IM53786L,SY4493660

New! Log in or create an account to see price and availability


MARKETING INFORMATION

The PEXUSB4DP is a low profile 4 port USB card designed for versatility and performance. Providing simple system expansion for added peripheral connections, this PCI Express USB card adds 3 external USB 2.0 slots and 1 internal USB 2.0 slot, with support for high speed USB 2.0 data transfer rates of up to 480 Mbps, and includes WHQL certified drivers and easy plug and play installation. Capable of adapting to virtually any PC case form factor, the low profile USB card includes a standard profile bracket for installation in full form factor cases.

More from the Manufacturer

More from the Manufacturer

DETAILS

  • Host Interface : PCI Express
  • Data Transfer Rate : 480 MB/s
  • Total Number of USB Ports : 4
  • Number of USB 2.0 Ports : 4
  • Form Factor : Plug-in Card
  • Height : 0.80" (20.32 mm)
  • Width : 3.10" (78.74 mm)
  • Length : 3.50" (88.90 mm)
  • Weight (Approximate) : 1.60 oz (45.36 g)
  • Package Contents :
    • 4 Port PCI Express Low Profile High Speed USB Card
    • 1 x Full Profile Bracket
    • 1 x Driver CD
    • 1 x Instruction Manual
  • Platform Supported : PC,Mac,Linux
  • Country of Origin : Taiwan
  • TAA Compliant : Yes
  • Environmentally Friendly : Yes
  • Limited Warranty : 2 Year
  • 3 external and 1 internal USB 2.0 port
  • High Speed USB 2.0 compliant, with transfer rates up to 480Mbps
  • Backward compatible with USB 1.0/1.1 devices
  • Provide up to 500mA of power per port with dedicated power input
  • Plug-and-Play compatible
  • Includes a full profile installation bracket

SPECIFICATIONS

Manufacturer StarTech.com
Manufacturer Part Number PEXUSB4DP
Manufacturer Website Address http://www.startech.com
Brand Name StarTech.com
Product Name 4 Port PCI Express Low Profile High Speed USB Card
Packaged Quantity 1 Each
Product Type USB Adapter
Host Interface PCI Express
Data Transfer Rate 480 MB/s
Total Number of USB Ports 4
Number of USB 2.0 Ports 4
Form Factor Plug-in Card
Height 0.80" (20.32 mm)
Width 3.10" (78.74 mm)
Length 3.50" (88.90 mm)
Thickness 0.79" (20.07 mm)
Weight (Approximate) 1.60 oz (45.36 g)
Package Contents
  • 4 Port PCI Express Low Profile High Speed USB Card
  • 1 x Full Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual
Additional Information OS Compatibility:
  • Windows® 2000, XP, Vista, 7, 8, 8.1, 10
  • Windows Server® 2003, 2008 R2, 2012, 2016, 2019
  • Mac OS X® 10.6 to 10.10
  • Linux 3.5.x to 4.11.x LTS versions only
Platform Supported Linux
Platform Supported Mac
Platform Supported PC
Country of Origin Taiwan
TAA Compliant Yes
Environmentally Friendly Yes
Limited Warranty 2 Year
