StarTech.com Quad Port 10G SFP+ Network Card - Intel XL710 Open SFP+ Converged Adapter - PCIe 10 Gigabit Fiber Optic Server NIC - 10GbE - Quad port SFP+ network card for MSA compliant SFP+ /DAC - 10 Gigabit Ethernet Card Intel XL710-BM2 10GbE converged network adapter - MMF & SMF Fiber - PCIe 3.0 x8

PEX10GSFP4I
Also known as IM5000DQ,SY5927767

New! Log in or create an account to see price and availability


MARKETING INFORMATION

This SFP+ server network card delivers reliable, high-performance network connectivity, by adding four open SFP+ slots to your server or high-powered workstation. It provides an easy and cost-effective way to upgrade to a 10 Gigabit fiber network using SFP+ modules of your choice and gives you the flexibility to use either multimode or single-mode fiber.

Add redundant connections in zero-downtime environments

With multiple available ports, you can avoid network downtime by adding fault-tolerant connections using two or more modules to provide high-bandwidth network links to your mission-critical servers or workstations.

Increase your network speed

This PCIe network card lets you take advantage of the increased speed and stability of a 10 Gigabit network, with data transfers of up to 10Gbps.

Add scalable network connections to your server or workstation

The network interface card is compatible with most 10GbE SFP+ transceivers. This gives you flexible and scalable configuration options, for connecting your computer directly to a fiber network at greater distances.

The card features four open SFP+ slots with support for interchangeable 10GBase SFP+ modules. This gives you the option to use the fiber transceiver modules that best suit your network needs based on distance and connector type. StarTech.com offers a wide variety of SFP+ transceiver modules to suit your network requirements. In addition, StarTech.com SFP+ cables provide a dependable solution for linking telecom and data communications equipment, such as routers and switches.

Enhance your network capabilities

The SFP+ server network card features the Intel® XL710 chipset, delivering the power, performance and enhanced capabilities you need for reliable connections to your server or computer. The Intel chip offers many advanced features including Intel® Virtualization Technology for Connectivity, PXE network boot support and up to 9K jumbo frame support.

The PEX10GSFP4I is backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

More from the Manufacturer

DETAILS

  • Chipset Manufacturer : Intel
  • Chipset Model : XL710
  • Host Interface : PCI Express x8
  • Total Number of Ports : 4
  • Expansion Slot Type : SFP+
  • Media Type Supported : Optical Fiber
  • Maximum Data Transfer Rate : 20 Gbit/s
  • Network Technology : 10GBase-LR,10GBase-SR
  • Color Family : Black
  • Product Color : Black
  • Form Factor : Plug-in Card
  • Height : 3.90" (99.06 mm)
  • Width : 0.60" (15.24 mm)
  • Depth : 5.50" (139.70 mm)
  • Weight (Approximate) : 4.30 oz (121.90 g)
  • Package Contents :
    • Quad-Port SFP+ Server Network Card - PCI Express - Intel XL710 Chip
    • 1 x Quick-start Guide
  • Device Supported : Server
  • Environmentally Friendly : Yes
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
  • Country of Origin : China
  • Limited Warranty : 2 Year
  • QUAD SFP+ ADAPTER: 4 ports on SFP+ network card can provide redundancy, or be aggregated for demanding applications; Data Center Bridging (DCB), virtualization incl. VT-c, SAN & iSCSI offload support
  • TECH SPECS: 10 Gbps per port | 4 SFP+ Ports, MSA Compliant | Intel XL710| MMF & SMF Fiber Support | PCIe 3.0 x8 | PXE Boot | 9K Jumbo Frames | Link Aggregation | VLAN | Full profile | 2 Yr. Warranty
  • TESTED & VERIFIED PERFORMANCE: We use Spirent SmartBits to validate performance; converged network adapter is compatible w/ leading servers like Dell PowerEdge, HPE ProLiant & Lenovo ThinkSystem
  • FLEXIBLE: Use MSA compliant SFP+ module or direct attach cable (DAC) supporting different fiber types; 10 Gigabit Ethernet NIC works w/leading brands of switches, routers, & devices like Cisco & HPE
  • WIDE HYPEVISOR & OS COMPATIBILITY: Fiber LAN card compatible w/Windows 7, 8, 8.1, 10; Windows Server 2008 R2, 2012, 2012 R2, 2016, 2019; Linux kernels 3.x + (LTS versions); VMWare ESXi 5.0, 5.1+

SPECIFICATIONS

Manufacturer StarTech.com
Manufacturer Part Number PEX10GSFP4I
Manufacturer Website Address http://www.startech.com
Brand Name StarTech.com
Product Name Quad-Port SFP+ Server Network Card - PCI Express - Intel XL710 Chip
Packaged Quantity 1 Each
Product Type 10Gigabit Ethernet Card
Chipset Manufacturer Intel
Chipset Model XL710
Host Interface PCI Express x8
Total Number of Ports 4
Expansion Slot Type SFP+
Media Type Supported Optical Fiber
Maximum Data Transfer Rate 20 Gbit/s
Network Technology 10GBase-SR
Network Technology 10GBase-LR
Color Family Black
Product Color Black
Form Factor Plug-in Card
Height 3.90" (99.06 mm)
Width 0.60" (15.24 mm)
Depth 5.50" (139.70 mm)
Weight (Approximate) 4.30 oz (121.90 g)
Package Contents
  • Quad-Port SFP+ Server Network Card - PCI Express - Intel XL710 Chip
  • 1 x Quick-start Guide
Device Supported Server
System Requirements
  • Windows® 7, 8, 8.1, 10
  • Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
  • (Windows Drivers are supported in 64-bit only)
  • Linux 2.6.24 to 4.11.x (64-bit Only)< LTS Versions only
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Environmental Compliance Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin China
Limited Warranty 2 Year
