StarTech.com 1 Port PCIe Ethernet Network Card - Add a 10/100Mbps Ethernet port to a desktop computer through a PCI Express slot - pci express ethernet adapter - pcie ethernet card - pci express ethernet nic -10/100 adapter card
PEX100S
Also known as IM43827H
MARKETING INFORMATION
This PCI Express based 10/100 Ethernet Card provides a simple way to connect a PCIe enabled server or workstation to a 10/100 Ethernet network and offers a broad range of features and functions, including support for both Full and Half Duplex operation as well as Wake On LAN (WOL) Power Management.
The PEX100S Ethernet Card includes both standard and low profile brackets and is compatible with most mATX (Slimline) and ATX system form factors, and features Auto MDI/MDIX automatic configuration, which helps to simplify installation and configuration.
More from the Manufacturer
DETAILS
- Chipset Manufacturer : Realtek
- Chipset Model : RTL8101E
- Host Interface : PCI Express
- Total Number of Ports : 1
- Number of Network (RJ-45) Ports : 1
- Media Type Supported : Twisted Pair
- Maximum Data Transfer Rate : 100 Mbit/s
- Network Technology : 10/100Base-TX
- Form Factor : Plug-in Card
- Height : 0.80" (20.32 mm)
- Width : 4.70" (119.38 mm)
- Weight (Approximate) : 1.10 oz (31.18 g)
- Package Contents :
- 1 Port PCI Express 10/100 Ethernet Network Interface Adapter Card
- 1 x Low Profile Bracket
- 1 x Instruction Manual
- 1 x Driver CD
- Environmentally Friendly : Yes
- Country of Origin : China
- Limited Warranty : 2 Year
- Single 10/100Mbps RJ45 Ethernet port
- Compliant with IEEE802.3 CSMA/CD, 802.3 10Base-T and 100Base-TX standards
- Crossover Detection & Auto-Correction (Auto-MDIX)
- Full and Half duplex mode support
- Link speed and duplex mode auto-negotiation
- Link/Activity and 10/100Mbps LED indicators
- Supports Wake-on-LAN
- Full/Low Profile installation brackets included
SPECIFICATIONS
| Manufacturer | StarTech.com |
| Manufacturer Part Number | PEX100S |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | 1 Port PCI Express 10/100 Ethernet Network Interface Adapter Card |
| Packaged Quantity | 1 Each |
| Product Type | Fast Ethernet Card |
| Chipset Manufacturer | Realtek |
| Chipset Model | RTL8101E |
| Host Interface | PCI Express |
| Total Number of Ports | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Media Type Supported | Twisted Pair |
| Twisted Pair Cable Standard | Category 5 |
| Maximum Data Transfer Rate | 100 Mbit/s |
| Network Technology | 10/100Base-TX |
| Form Factor | Plug-in Card |
| Height | 0.80" (20.32 mm) |
| Width | 4.70" (119.38 mm) |
| Length | 3.60" (91.44 mm) |
| Weight (Approximate) | 1.10 oz (31.18 g) |
| Package Contents |
|
| System Requirements |
|
| Environmentally Friendly | Yes |
| Country of Origin | China |
| Limited Warranty | 2 Year |
