StarTech.com 3 Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps - Running low on expansion slots? Merge USB 3.0 and GbE into a single PCIe combo card - 3 Port PCI Express USB 3.0 Card + Gigabit Ethernet - Fits Standard & Low-Profile PCs - UASP - SATA Power - USB 3 with Network Adapter Card -

PEXUSB3S3GE
Also known as IM40514Y,SY5446704

New! Log in or create an account to see price and availability


MARKETING INFORMATION

This PCIe USB 3.2 Gen 1 card couples your peripheral and network connections into a single, scalable solution.
By combining three USB 3.2 Gen 1 ports and one RJ45 port onto a single card, you only need a single PCIe slot for installation, which lets you free up space for other add-ons or upgrades and get more out of your desktop or server.
If you have separate cards for your USB and network connections, this versatile card overcomes the aggravation of running out of PCIe slots while helping to reduce clutter inside your PC.
This dual-purpose card is perfect for building or upgrading your computer. It helps you save money by avoiding the additional costs of purchasing separate USB 3.2 Gen 1 and Gigabit Ethernet adapters.
You can rest assured this card will fit in your small form-factor system, if needed. It features a dual-profile design that makes it easy to install in either standard or low-profile cases.
The combo card makes it easy to connect peripherals such as your external hard drives or mobile devices. Plus, it's backward compatible with USB 2.0 and 1.x, so you won't have to replace all of your existing USB devices.
Functioning as a network adapter, the card delivers wired network access in locations where Wi-Fi is unavailable or unreliable.
Support for advanced features such as jumbo frames and VLAN tagging means you can optimize network traffic as needed.
This high-performance SuperSpeed USB 3.2 Gen 1 adapter card supports data transfer rates up to 5 Gbps and is enhanced with UASP support, which can perform ~70% faster read speed and 40% faster write speed over traditional USB 3.2 Gen 1, when paired with a
The PEXUSB3S3GE is backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

DETAILS

  • Host Interface : PCI Express x1
  • UASP Support : Yes
  • Total Number of USB Ports : 3
  • Number of USB 3.2 Ports : 3
  • Number of Network (RJ-45) Ports : 1
  • Operating System Supported : Windows XP,Windows Vista,Windows 7,Windows 8,Windows 8.1,Windows 10,Windows 11,Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019,Linux
  • Color Family : Red
  • Product Color : Red
  • Form Factor : Plug-in Card
  • Height : 4.70" (119.38 mm)
  • Width : 0.70" (17.78 mm)
  • Length : 3" (76.20 mm)
  • Weight (Approximate) : 2.10 oz (59.53 g)
  • Package Contents :
    • 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps
    • 1 x Low-Profile Bracket
    • 1 x Driver CD
    • 1 x Instruction Manual
  • Platform Supported : PC,Linux
  • Country of Origin : Taiwan
  • TAA Compliant : Yes
  • Environmentally Friendly : Yes
  • Limited Warranty : 2 Year
  • Frees up a PCIe slot by consolidating 3x USB 3.0 & 1x Gigabit Ethernet ports into a single card
  • Provides installation flexability for standard and low-profile computers, with a dual-profile design
  • Lets you save money and connect your existing devices with USB 2.0 and 1.x backward compatibility
  • Perfect for high-powered USB devices, with optional SATA power providing up to 900mA per port
  • PCIe x1 interface, compliant with PCI Express 2.0 specifications
  • Supports Wake-On-LAN, Energy-Efficient Ethernet, jumbo frames, full duplex flow control, VLAN tagging, and layer 2 priority encoding

SPECIFICATIONS

Manufacturer StarTech.com
Manufacturer Part Number PEXUSB3S3GE
Manufacturer Website Address http://www.startech.com
Brand Name StarTech.com
Product Name 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps
Packaged Quantity 1 Each
Product Type USB Adapter
Host Interface PCI Express x1
UASP Support Yes
Total Number of USB Ports 3
Number of USB 3.2 Ports 3
Number of Network (RJ-45) Ports 1
Operating System Supported Linux
Operating System Supported Windows Server 2019
Operating System Supported Windows Server 2012
Operating System Supported Windows Server 2008 R2
Operating System Supported Windows 11
Operating System Supported Windows 10
Operating System Supported Windows 8.1
Operating System Supported Windows 8
Operating System Supported Windows 7
Operating System Supported Windows Vista
Operating System Supported Windows XP
Operating System Supported Windows Server 2016
Color Family Red
Product Color Red
Form Factor Plug-in Card
Height 4.70" (119.38 mm)
Width 0.70" (17.78 mm)
Length 3" (76.20 mm)
Weight (Approximate) 2.10 oz (59.53 g)
Package Contents
  • 3-Port PCI Express USB 3.0 Card + Gigabit Ethernet - 5Gbps
  • 1 x Low-Profile Bracket
  • 1 x Driver CD
  • 1 x Instruction Manual
Additional Information
  • Windows® 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64)
  • Windows Server® 2012, 2008 R2
  • Linux 2.6.31 and later (tested up to 3.5)
  • Platform Supported PC
    Platform Supported Linux
    Country of Origin Taiwan
    TAA Compliant Yes
    Environmentally Friendly Yes
    Limited Warranty 2 Year
