Cisco HyperFlex HX220c M5 2U Rack Server - 2 Xeon Silver 4210R 2.40 GHz - 128 GB RAM - Intel C620 Chip - 2 Processor Support - 3 TB RAM Support - DDR4 SDRAM - Pilot 4 Up to 16 MB Graphic Card - 10 Gigabit Ethernet - Hot Swappable Bays
HX-SP-220M5C-E1
Also known as IM357A9H
MARKETING INFORMATION
Cisco HyperFlex™ Systems unlock the full potential of hyperconvergence. The systems are based on an end-to-end software-defined infrastructure, combining software-defined computing in the form of Cisco Unified Computing System (Cisco UCS) servers; software-defined storage with the powerful Cisco HX Data Platform and software-defined networking with the Cisco UCS fabric that will integrate smoothly with Cisco Application Centric Infrastructure (Cisco ACI™). Together with a single point of connectivity and hardware management, these technologies deliver a preintegrated and adaptable cluster that is ready to provide a unified pool of resources to power applications as your business needs dictate.The HX220c M5 servers extend the capabilities of Cisco's HyperFlex portfolio in a 1U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots with configuration options ranging from 128GB up to 3TB of DRAM, and an all flash footprint of cache and capacity drives for highly available, high performance storage.
The latest update includes support for 2nd Generation Intel® Xeon® Scalable Processors, 2933-MHz DDR4 memory.
DETAILS
- Number of Processors Supported : 2
- Number of Processors Installed : 2
- Processor Type : Xeon Silver
- Processor Generation : 2nd Gen
- Processor Model : 4210R
- Processor Core : Deca-core (10 Core)
- Processor Speed : 2.40 GHz
- Chipset Manufacturer : Intel
- Chipset Model : C620
- Standard Memory : 128 GB
- Maximum Memory Supported : 3 TB
- Memory Technology : DDR4 SDRAM
- Total Number of Memory Slots : 24
- Number of Occupied Memory Slots : 4
- Error Checking : ECC
- Signal Processing : Registered (Buffered)
- Hot Swappable Bays : Yes
- Graphics Controller Model : Pilot 4
- Graphics Memory Capacity : 16 MB
- Ethernet Technology : 10 Gigabit Ethernet
- Total Number of USB Ports : 2
- Number of USB 3.0 Ports : 2
- Network (RJ-45) : Yes
- VGA : Yes
- Input Voltage : 120 V AC,230 V AC
- Number of Power Supplies Supported : 2
- Country of Origin : United States
- Form Factor : Rack
- Rack Height : 2U
- Height : 1.70" (43.18 mm)
- Width : 18.98" (482.09 mm)
- Depth : 30.98" (786.89 mm)
- Weight (Approximate) : 37.50 lb (17009.71 g)
- With 128 GB memory, users can run multiple programs simultaneously without losing performance
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
SPECIFICATIONS
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | HX-SP-220M5C-E1 |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Line | HyperFlex |
| Product Series | HX220c M5 |
| Product Name | Hyperflex HX220c M5 Server |
| Product Type | Server |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 2 |
| Processor Type | Xeon Silver |
| Processor Generation | 2nd Gen |
| Processor Model | 4210R |
| Processor Core | Deca-core (10 Core) |
| Processor Speed | 2.40 GHz |
| Chipset Manufacturer | Intel |
| Chipset Model | C620 |
| Standard Memory | 128 GB |
| Maximum Memory Supported | 3 TB |
| Memory Technology | DDR4 SDRAM |
| Error Checking | ECC |
| Total Number of Memory Slots | 24 |
| Number of Occupied Memory Slots | 4 |
| Signal Processing | Registered (Buffered) |
| Hot Swappable Bays | Yes |
| Graphics Controller Model | Pilot 4 |
| Graphics Memory Capacity | 16 MB |
| Ethernet Technology | 10 Gigabit Ethernet |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Network (RJ-45) | Yes |
| VGA | Yes |
| Number of VGA Ports | 1 |
| Input Voltage | 230 V AC |
| Input Voltage | 120 V AC |
| Number of Power Supplies Supported | 2 |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 1.70" (43.18 mm) |
| Width | 18.98" (482.09 mm) |
| Depth | 30.98" (786.89 mm) |
| Weight (Approximate) | 37.50 lb (17009.71 g) |
| Country of Origin | United States |
