Star Micronics TSP143IVUE Thermal Receipt Printer - TSP100IV, Thermal, Cutter, USB-C, Ethernet (LAN), CloudPRNT, Android Open Accessory (AOA), Gray, Ethernet and USB Cable, Int PS - TSP100IV, Thermal, Cutter, USB-C, Ethernet (LAN), CloudPRNT, Android Open Accessory (AOA), Gray, Ethernet and USB Cabl
39473010
Also known as IM01HW52
MARKETING INFORMATION
With included internal power supply, power cable, USB cable, LAN cable and complete mounting kits, and paper roll, the TSP143IVUE is the perfect printer for any mPOS bundle. Star has also added an additional USB type-A connector for one convenient power source for your Android tablet or mobile device. The TSP143III prints at a high-speed of 43 RPM (250mm/s) and includes "Drop-In and Print" paper loading and a guillotine auto-cutter.
DETAILS
- Recommended Use : Receipt Print
- Print Color Capability : Monochrome
- Maximum Mono Print Speed : 9.84 in/s (250 mm/s)
- Maximum Print Resolution (dpi) : 203
- Barcode Symbology Supported : PDF417,Maxi Code
- Character Sets : ANK 95
- Connectivity Technology : Wired
- Fonts Included : 12 x 24
- Application/Usage : Desktop
- Features : Compact,Auto-cutter
- USB Host : Yes
- USB : Yes
- Ethernet : Yes
- Ethernet Technology : Ethernet
- Cutter : Yes
- Cutting Method : Automatic
- Cutter Type : Guillotine
- Cut Type : Partial Cut
- Cutter Life : 2000000 Cuts
- Media Type : Receipt
- Media Size : 3.15" (80 mm)
- Media Sensor : Out Of Paper Sensor,Cover Open Sensor
- Maximum Roll Diameter : 3.3" (83 mm)
- Maximum Label Width : 3.15" (80 mm)
- Mean Cycles Between Failures (MCBF) : 60000000
- Print Head Life : 100km
- Power Source : Power Adapter
- Operating Temperature : 41°F (5°C) - 113°F (45°C)
- Operating Relative Humidity : 10% - 90%
- Storage Temperature : -4°F (-20°C) - 140°F (60°C)
- Storage Relative Humidity : 10% - 90%
- Form Factor : Wall Mount
- Product Color : Gray
- Height : 4.84" (123 mm)
- Width : 5.51" (140 mm)
- Depth : 6.65" (169 mm)
- Weight (Approximate) : 2.87 lb (1300 g)
- Package Contents :
- TSP143IV Thermal Receipt Printer
- Internal Power Supply
- Power Cable
- USB Cable
- LAN Cable
- Complete Mounting Kits
- Paper Roll
- Cables Included : USB
- Optional Connectivity : Wireless LAN
- Platform Supported : iOS,PC,Android,Mac
- Certifications & Standards :
UL, C-UL, TuV, FCC, VCCI, EN55022 {This is one part of FCC testing probably do not need to list it}, CE
- The printer is capable of printing sharp and detailed monochrome documents quickly
- Optimize your workflows by sharing the resources of the printer via Ethernet connectivity
SPECIFICATIONS
| Manufacturer | Star Micronics, Inc |
| Manufacturer Part Number | 39473010 |
| Manufacturer Website Address | http://www.starmicronics.com |
| Brand Name | Star Micronics |
| Product Series | TSP143IV |
| Product Model | TSP143IVUE GRY US |
| Product Name | TSP143IV Thermal Receipt Printer |
| Product Type | Direct Thermal Printer |
| Recommended Use | Receipt Print |
| Print Color Capability | Monochrome |
| Maximum Mono Print Speed | 9.84 in/s (250 mm/s) |
| Maximum Print Resolution (dpi) | 203 |
| Barcode Symbology Supported | PDF417 |
| Barcode Symbology Supported | Maxi Code |
| Application/Usage | Desktop |
| Features | Compact |
| Features | Auto-cutter |
| Mean Cycles Between Failures (MCBF) | 60000000 |
| Character Sets | ANK 95 |
| Print Head Life | 100km |
| Connectivity Technology | Wired |
| Optional Connectivity | Wireless LAN |
| Fonts Included | 12 x 24 |
| Print Technology | Direct Thermal |
| USB Host | Yes |
| USB | Yes |
| Ethernet | Yes |
| Ethernet Technology | Ethernet |
| Cutter | Yes |
| Cutting Method | Automatic |
| Cutter Type | Guillotine |
| Cut Type | Partial Cut |
| Cutter Life | 2000000 Cuts |
| Media Type | Receipt |
| Media Size | 3.15" (80 mm) |
| Media Sensor | Cover Open Sensor |
| Media Sensor | Out Of Paper Sensor |
| Maximum Roll Diameter | 3.3" (83 mm) |
| Maximum Label Width | 3.15" (80 mm) |
| Software Included | Windows Drivers OPOS Driver JavaPOS Drivers (Windows/Mac/Linux) CUPS Drivers (Mac/Linux) StarXpand SDK (React Native, iOS, Android) StarPRNT SDK (iOS/Android/Windows Desktop/UWP) Star WebPRNT Browser (Android) Star PassPRNT (iOS/Android/UWP) CloudPRNT SDK |
| Power Source | Power Adapter |
| Operating Temperature | 41°F (5°C) - 113°F (45°C) |
| Operating Relative Humidity | 10% - 90% |
| Storage Temperature | -4°F (-20°C) - 140°F (60°C) |
| Storage Relative Humidity | 10% - 90% |
| Form Factor | Wall Mount |
| Color Family | Gray |
| Product Color | Gray |
| Height | 4.84" (123 mm) |
| Width | 5.51" (140 mm) |
| Depth | 6.65" (169 mm) |
| Weight (Approximate) | 2.87 lb (1300 g) |
| Package Contents |
|
| Cables Included | USB |
| Platform Supported | iOS |
| Platform Supported | Mac |
| Platform Supported | Android |
| Platform Supported | PC |
| Certifications & Standards | UL, C-UL, TuV, FCC, VCCI, EN55022 {This is one part of FCC testing probably do not need to list it}, CE |
