APC by Schneider Electric Smart-UPS C 1000VA LCD RM 2U 120V with SmartConnect - 2U Rack-mountable - 3 Hour Recharge - 9.20 Minute Stand-by - 120 V Input - 120 V AC Output - Sine Wave - 6 x NEMA 5-15R Receptacle(s) - 6 x Battery/Surge Outlet
SMC1000-2UC
Also known as DHSMC10002UCCA,IM6599EA,SY6029484
MARKETING INFORMATION
This APC Smart-UPS is designed for small to medium business owners to maintain business uptime and continuity. This 1000VA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. The UPS comes with NEMA 5-15P input and 6x NEMA 5-15R outlets. This UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS C has an intuitive graphic LCD interface. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. This line interactive UPS operates in green mode for high operating efficiency. Connect to either monitoring software using the Port on the back of the device. The SMC has a 2-year warranty, and comes with a built-in lead-acid battery. This UPS provides surge protection against lightning strikes, power sags, brownouts and surges. This is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. This 600 watt UPS offers a green mode to ensure you are operating at the highest level of efficiency while it's smart battery management maximizes performance. Automatic Voltage Regulation (AVR) adjusts voltages ensuring reliable power while preserving battery life. Predictive battery management provides an estimated date of when battery replacement is recommended. UPS, Documentation CD, Installation guide, Rack mounting brackets, USB cable.DETAILS
- Plug/Connector Type : NEMA 5-15P
- Receptacle Type : NEMA 5-15P
- Receptacle Detail : 6 x NEMA 5-15R
- Number of Battery & Surge Outlets : 6
- Cord Length : 8 ft (2.44 m)
- Transfer Time : 10 ms
- Application/Usage : Server,Router,Switch,Network Hub,Network Device,POS Terminal
- Load Capacity (VA) : 1 kVA
- Load Capacity (Watt) : 600 W
- Input Voltage : 120 V
- Input Voltage Range : 93 V AC - 130 V AC
- Output Voltage : 120 V AC
- Waveform Type : Sine Wave
- Surge Energy Rating : 680 J
- Network Management : SmartConnect
- Network (RJ-45) : Yes
- Battery Chemistry : Lead Acid
- Backup/Run Time (Full Load) : 9.20 Minute
- Hot Swappable : Yes
- Typical Battery Recharge Time : 3 Hour
- Product Color : Black
- Height : 3.39" (86 mm)
- Width : 17.01" (432 mm)
- Depth : 15.98" (406 mm)
- Rack Height : 2U
- Form Factor : Rack-mountable
- Weight (Approximate) : 45.24 lb (20520.52 g)
- Package Contents :
- Smart-UPS C 1000VA LCD RM 2U 120V with SmartConnect
- Documentation CD
- Installation guide
- Rack mounting brackets
- USB cable
- Energy Star : Yes
- Country of Origin : Philippines
- Environmentally Friendly : Yes
- Environmental Compliance : Restriction of Hazardous Substances (RoHS)
- Limited Warranty : 2 Year
- Additional Warranty Information : 2 years repair or replace
- 600 W load capacity - backup power for your valuable electronics
- Up to 9.20 minute runtime on full load to preserve critical data from power shortage interruptions
- 1 kVA load capacity provides sufficient backup during power failures
SPECIFICATIONS
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | SMC1000-2UC |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Smart-UPS |
| Product Name | Smart-UPS C 1000VA LCD RM 2U 120V with SmartConnect |
| Packaged Quantity | 1 |
| Product Type | Line-interactive UPS |
| Plug/Connector Type | NEMA 5-15P |
| Receptacle Type | NEMA 5-15P |
| Receptacle Detail | 6 x NEMA 5-15R |
| Number of Battery & Surge Outlets | 6 |
| Cord Length | 8 ft (2.44 m) |
| Transfer Time | 10 ms |
| Application/Usage | Server |
| Application/Usage | Router |
| Application/Usage | Switch |
| Application/Usage | Network Hub |
| Application/Usage | Network Device |
| Application/Usage | POS Terminal |
| Load Capacity (VA) | 1 kVA |
| Load Capacity (Watt) | 600 W |
| Input Voltage | 120 V |
| Input Voltage Range | 93 V AC - 130 V AC |
| Output Voltage | 120 V AC |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 680 J |
| Network Management | SmartConnect |
| Network (RJ-45) | Yes |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 9.20 Minute |
| Typical Battery Recharge Time | 3 Hour |
| Hot Swappable | Yes |
| Color Family | Black |
| Product Color | Black |
| Height | 3.39" (86 mm) |
| Width | 17.01" (432 mm) |
| Depth | 15.98" (406 mm) |
| Rack Height | 2U |
| Form Factor | Rack-mountable |
| Mounting Preference | Lower |
| Mounting Location | Front |
| Weight (Approximate) | 45.24 lb (20520.52 g) |
| For Country/Region | United States |
| Package Contents | |
| Certifications & Standards | cULus|ENERGY STAR V2.0 (USA) |
| Energy Star | Yes |
| Optimized Energy Efficiency | Yes |
| Product Take Back Program | Yes |
| Mercury Free | Yes |
| RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMC1000-2UC_ROHS_DECLARATION&p_FileName=SMC1000-2UCKIT_ROHS_DECLARATION_US.pdf |
| REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=465940260&lang=en-us |
| EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=465940260&lang=en-us |
| Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612028_EN |
| End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612028_EN |
| California Proposition 65 Warning | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Energy Star URL | https://www.energystar.gov/products/uninterruptible_power_supplies |
| REACH free of SVHC | No |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | 2 Year |
| Additional Warranty Information | 2 years repair or replace |
| Directly Connected Equipment Guarantee | $150000 Lifetime |
