MARKETING INFORMATION

Axiom's DDR4 Modules use the latest evolutionary DRAM design, provides improved speed, power management and reliability. The release of DDR4 delivers an overall performance improvement of up to 30% for single DIMM configurations. DDR4 performance scales up to 65% faster in 3-DIMM per channel (3DPC) applications over DDR3.

High bandwidth and faster data rates combined with lower voltage demands deliver the most compelling and significant DRAM computing update in the past decade.

DDR4 Features:

100% Increase in speed - Faster Data Rate equates to more responsive application loads on data-intensive programs.

300% increase in component densities - Equals larger modules for next-generation performance demands.

20% decrease in power consumption - Less power consumed means less wasted resources to cool systems and reserves battery program for mobile devices.

Provides greater reliability, availability and serviceability (RAS) in enterprise applications - Complete integrity and fault tolerance for longer periods without system failure.

Improved data signal.

DETAILS

• Memory Size : 32 GB
• Memory Technology : DDR4 SDRAM
• Memory Voltage : 1.20 V
• Memory Speed : 3200 MHz
• Memory Standard : DDR4-3200/PC4-25600
• Error Checking : ECC
• Signal Processing : Registered
• CAS Latency : CL22
• Device Supported : Server
• Number of Pins : 288-pin
• Form Factor : RDIMM
• Compatibility :

  Dell PowerEdge R6515 Server

• Environmentally Friendly : Yes
• Environmental Compliance : Restriction of Hazardous Substances (RoHS)
• Limited Warranty : Lifetime

• 3200 MHz of memory speed skillfully manages the variety of apps and computational tasks
• 32 GB of memory to maintain symmetry with processor and hard drive and bring out the ultimate computing experience
• 288-pin-pin DDR4-3200/PC4-25600 interface synchronizes electrical and clock signals for an efficient data transfer rate
