MARKETING INFORMATION

LENOVO YOGA

DETAILS

• Release Month : May
• Release Year : 2023
• Processor Manufacturer : AMD
• Processor Type : Ryzen 5
• Processor Model : 7530U
• Processor Speed : 2 GHz
• Maximum Turbo Speed : 4.50 GHz
• Processor Core : Hexa-core (6 Core)
• Processor Threads : 12
• Chipset Manufacturer : AMD
• Total Installed System Memory : 8 GB
• Maximum Supported System Memory : 12 GB
• System Memory Technology : DDR4 SDRAM
• System Memory Speed : 3200 MHz
• System Memory Form Factor : On-board + SoDIMM
• Installed Slot Memory : 4 GB
• On-board Memory : 4 GB
• On-board Memory Technology : DDR4 SDRAM
• Total Number of Memory Slots : 1
• Number of Occupied Memory Slots : 1
• Drive Type : SSD
• Total Solid State Drive Capacity : 256 GB
• SSD Form Factor : M.2
• Screen Size : 13.3"
• Screen Mode : WUXGA
• Display Screen Technology : In-plane Switching (IPS) Technology
• Screen Resolution : 1920 x 1200
• Brightness : 300 cd/m²
• Color Gamut : 45% NTSC
• Standard Refresh Rate : 60 Hz
• Touchscreen : Yes
• Graphics Controller Manufacturer : AMD
• Graphics Controller Model : Radeon Graphics
• Graphics Memory Technology : DDR4 SDRAM
• Graphics Memory Accessibility : Shared
• Wireless LAN : Yes
• Wireless LAN Standard : IEEE 802.11ax
• Wimax : No
• Bluetooth : Yes
• WWAN Supported : No
• Camera Privacy Shutter : Yes
• Front Camera/Webcam : Yes
• Rear Camera : Yes
• Rear Camera Resolution : 5 Megapixel
• Finger Print Reader : Yes
• HDMI : Yes
• Total Number of USB Ports : 4
• Number of USB 3.2 Gen 1 Ports : 2
• Number of USB 3.2 Gen 1 Type-C Ports : 2
• Operating System Platform : Windows
• Operating System : Windows 11 Pro
• Operating System Language : English
• Keyboard Localization : English (US)
• Keyboard Backlight : Yes
• Maximum Power Supply Wattage : 65 W
• USB Power Delivery Support : Yes
• Color Family : Black
• Product Color : Thunder Black
• Cover Material : Acrylonitrile Butadiene Styrene (ABS),Polycarbonate,Aluminum
• Form Factor : Convertible
• Height : 0.78" (19.70 mm)
• Width : 12.01" (305 mm)
• Depth : 8.54" (216.80 mm)
• Weight (Approximate) : 3.20 lb (1450 g)
• Package Contents :
• 13w Yoga Gen 2
• Power Adapter
• Lenovo Integrated Pen, on-board garaged, rechargeable, supports AES protocol
• Charger Included : Yes
• Energy Star : Yes
• Features : Corning Gorilla Glass,OGM (On-glass Metal mesh),Anti-fingerprint
• Environmentally Friendly : Yes
• Environmental Certification : TCO Certified 9.0,Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),ENERGY STAR 8.0
• Energy Efficiency Compliance : Energy-related Pro

  SPECIFICATIONS

  Manufacturer	Lenovo Group Limited
  Manufacturer Part Number	82YR0009US
  Manufacturer Website Address	http://www.lenovo.com
  Brand Name	Lenovo
  Product Series	13w Yoga Gen 2
  Product Model	82YR0009US
  Product Name	13w Yoga Gen 2
  Product Type	2 in 1 Notebook
  Release Month	May
  Release Year	2023
  Processor Manufacturer	AMD
  Processor Type	Ryzen 5
  Processor Model	7530U
  Processor Core	Hexa-core (6 Core)
  Processor Speed	2 GHz
  Maximum Turbo Speed	4.50 GHz
  L2 Cache	3 MB
  L3 Cache	16 MB
  Processor Threads	12
  Chipset Manufacturer	AMD
  Total Installed System Memory	8 GB
  Maximum Supported System Memory	12 GB
  System Memory Technology	DDR4 SDRAM
  System Memory Speed	3200 MHz
  System Memory Form Factor	On-board + SoDIMM
  Installed Slot Memory	4 GB
  On-board Memory	4 GB
  On-board Memory Technology	DDR4 SDRAM
  Total Number of Memory Slots	1
  Number of Occupied Memory Slots	1
  Memory Card Reader	Yes
  Drive Type	SSD
  Total Solid State Drive Capacity	256 GB
  SSD Form Factor	M.2
  Screen Size	13.3"
  Display Screen Technology	In-plane Switching (IPS) Technology
  Standard Refresh Rate	60 Hz
  Screen Mode	WUXGA
  Screen Resolution	1920 x 1200
  Brightness	300 cd/m²
  Color Gamut	45% NTSC
  Touchscreen	Yes
  Graphics Controller Manufacturer	AMD
  Graphics Controller Model	Radeon Graphics
  Graphics Memory Technology	DDR4 SDRAM
  Graphics Memory Accessibility	Shared
  Wireless LAN	Yes
  Wireless LAN Standard	IEEE 802.11ax
  Wimax	No
  Bluetooth	Yes
  WWAN Supported	No
  Camera Privacy Shutter	Yes
  Front Camera/Webcam	Yes
  Rear Camera	Yes
  Rear Camera Resolution	5 Megapixel
  Finger Print Reader	Yes
  HDMI	Yes
  Total Number of USB Ports	4
  Number of USB 3.2 Gen 1 Ports	2
  Number of USB 3.2 Gen 1 Type-C Ports	2
  Operating System Platform	Windows
  Operating System	Windows 11 Pro
  Operating System Language	English
  Keyboard Backlight	Yes
  Keyboard Localization	English (US)
  Battery Chemistry	Lithium Polymer (Li-Polymer)
  Maximum Power Supply Wattage	65 W
  USB Power Delivery Support	Yes
  Power Plug Type	Type C
  Color Family	Black
  Product Color	Thunder Black
  Cover Material	Polycarbonate
  Cover Material	Aluminum
  Cover Material	Acrylonitrile Butadiene Styrene (ABS)
  Form Factor	Convertible
  Height	0.78" (19.70 mm)
  Width	12.01" (305 mm)
  Depth	8.54" (216.80 mm)
  Weight (Approximate)	3.20 lb (1450 g)
  Package Contents	13w Yoga Gen 2 Power Adapter Lenovo Integrated Pen, on-board garaged, rechargeable, supports AES protocol
  Charger Included	Yes
  Features	Corning Gorilla Glass
  Features	OGM (On-glass Metal mesh)
  Features	Anti-fingerprint
  Energy Star	Yes
  TCO Certified	Yes
  Limited Warranty	1 Year
  Additional Warranty Information	1-year, Mail-in
  Environmentally Friendly	Yes
  Environmental Certification	Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
  Environmental Certification	TCO Certified 9.0
  Environmental Certification	ENERGY STAR 8.0
  Energy Efficiency Compliance	Energy-related Products Directive Lot 26 (ErP Lot 26)
  Energy Efficiency Compliance	Energy-related Products Directive Lot 6 (ErP Lot 6)
  Environmental Compliance	Restriction of Hazardous Substances (RoHS)
