MARKETING INFORMATION

Extend intent-based networking everywhere

Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.

As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.

Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.

With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access.

DETAILS

• Total Number of Network Ports : 48
• Uplink Port : Yes
• Modular : Yes
• Stack Port : Yes
• Port/Expansion Slot Details : 48 x Gigabit Ethernet Network,4 x 10 Gigabit Ethernet Uplink
• Media Type Supported : Twisted Pair,Optical Fiber
• Ethernet Technology : Gigabit Ethernet,10 Gigabit Ethernet
• Network Technology : 10/100/1000Base-T,10GBase-X
• Total Number of Expansion Slots : 4
• Expansion Slot Type : SFP+
• Shared SFP Slot : No
• Number of SFP+ Slots : 4
• Layer Supported : 3
• Manageable : Yes
• PoE (RJ-45) Port : Yes
• Power Source : Power Supply
• Redundant Power Supply Supported : Yes
• Number of Power Supplies Supported : 2
• Form Factor : Rack-mountable
• Height : 1.73" (43.94 mm)
• Width : 17.50" (444.50 mm)
• Depth : 11.30" (287.02 mm)
• Weight (Approximate) : 10.58 lb (4799.01 g)

• Stack port provides an easy and hassle-free way to extend your office network
• Quickly and easily set up a wired network with 48 networking ports
• Can work as layer 3 routing for scalable network design
• Managed switch provides a reliable foundation for your network
• Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
• Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components

SPECIFICATIONS
