Cisco Catalyst C1000-24FP-4G-L Ethernet Switch - 24 Ports - Manageable - 2 Layer Supported - Modular - 4 SFP Slots - Twisted Pair, Optical Fiber - Rack-mountable - Lifetime Limited Warranty
C1000-24FP-4G-L
Also known as C100024FP4GLCA,IM360LLJ
MARKETING INFORMATION
Cisco® Catalyst® 1000 Series Switches are fixed managed Gigabit Ethernet enterprise-class Layer 2 switches designed for small businesses and branch offices. These are simple, flexible and secure switches ideal for out-of-the-wiring-closet and critical Internet of Things (IoT) deployments. Cisco® Catalyst® 1000 operate on Cisco IOS® Software and support simple device management and network management via a Command-Line Interface (CLI) as well as an on-box web UI. These switches deliver enhanced network security, network reliability, and operational efficiency for Small and Medium Sized (SMB) organizations.DETAILS
- Total Number of Network Ports : 24
- Uplink Port : Yes
- Modular : Yes
- Port/Expansion Slot Details : 24 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Uplink,1 x Ethernet Network
- Media Type Supported : Twisted Pair,Optical Fiber
- Ethernet Technology : Gigabit Ethernet
- Network Technology : 10/100/1000Base-T,1000Base-X
- Total Number of Expansion Slots : 4.0
- Expansion Slot Type : SFP (mini-GBIC)
- Number of SFP Slots : 4
- Layer Supported : 2
- Manageable : Yes
- Power Source : Power Supply
- Form Factor : Rack-mountable
- Height : 1.73" (43.94 mm)
- Width : 17.50" (444.50 mm)
- Depth : 13.59" (345.19 mm)
- Weight (Approximate) : 10.14 lb (4600 g)
- Environmentally Friendly : Yes
- Environmental Compliance : Restriction of Hazardous Substances (RoHS)
- Country of Origin : China
- Limited Warranty : Lifetime
- Quickly and easily set up a wired network with 24 networking ports
- Built-in power supply to ensure all components are being supplied with accurate voltage
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Rack mounting enables you to organize wires & secure cables for professional installation
- Managed switch provides a reliable foundation for your network
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
SPECIFICATIONS
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | C1000-24FP-4G-L |
| Manufacturer Website Address | http://www.cisco.com |
| Brand Name | Cisco |
| Product Line | Catalyst |
| Product Series | 1000 |
| Product Model | C1000-24FP-4G-L |
| Product Name | Catalyst C1000-24FP-4G-L Ethernet Switch |
| Product Type | Ethernet Switch |
| Total Number of Network Ports | 24 |
| Uplink Port | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Uplink |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE+ |
| Port/Expansion Slot Details | 1 x Ethernet Network |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-X |
| Network Technology | 10/100/1000Base-T |
| Total Number of Expansion Slots | 4.0 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 4 |
| Layer Supported | 2 |
| Manageable | Yes |
| Power Source | Power Supply |
| Form Factor | Rack-mountable |
| Height | 1.73" (43.94 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 13.59" (345.19 mm) |
| Weight (Approximate) | 10.14 lb (4600 g) |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Limited Warranty | Lifetime |
